Comtech EF Data CPA - Manual (Page 72)

CPA C-Band Indoor Solid-State Power Amplifier Revision 1
Front Panel Operation MN/CPA-IN.IOM
5–16
MONITOR: Faults  Other
BUC = OK
ExtRef = OK (E)
5.3.2.2 MONITOR: Stored
Stored Events: View
Clear-All (◄ ► E)
Use the
◄ ► arrow keys to select View or Clear-All, and then press ENTER.
MONITOR: Stored  View
Log05: 10/11/10 10:37:32
Info - Log CLEAR (▲ ▼)
Use the ▲▼ arrow keys to scroll backwards or forwards through the entries in the stored
events log. Press ENTER or CLEAR to return to the previous menu.
The stored events log can store up to 255 events. The top line of the display indicates the
log entry number, and the date and time of the entry.
Note that in accordance with European convention, the date is shown in DAY-
MONTH-YEAR format.
The bottom line of the display provides a description of the logged and stored event.
MONITOR: Stored  Clear-All
Clear All Stored Events:
No Yes (◄ ► E)
Use the ◄ ► arrow keys to choose No or Yes, and then press ENTER.
If Yes is selected, the stored events log is cleared, and you are taken directly back to the
previous menu.
5.3.2.3 MONITOR: Power
Forward Power: <19.0 dBm
Reverse Power: <12.0 dBm
5.3.2.4 MONITOR: Vltgs
+15V=14.6 +7.5V=7.9
+5V=5.0 -5V=-5.0 (E)
