CPA C-Band Indoor Solid-State Power Amplifier Revision 1
Front Panel Operation MN/CPA-IN.IOM
5–8
If selecting CONFIG: Remote → Serial Config →Format :
Serial Port Data Format:
8 Data, 1 Stop, Par None
Use the ▲▼ arrow keys to select the serial port data format of the remote control bus
connected locally to the user PC, and then press ENTER. Note the following:
Data Bits Select 7 or 8.
Stop Bits Select 1 or 2.
Parity Select Odd, Even, or None.
The asynchronous character format default is 8 data bits, 1 stop bit, and no parity (8-N-1).
CONFIG: Remote  Ethernet
In Remote  Ethernet mode, serial monitoring is allowed; however, serial control
is not allowed except for use of the LRS (Local/Remote Status) commands/queries
Ethernet Config: Gateway
Address MAC SNMP (◄ ►)
Select the parameter to configure – Gateway, Address, MAC, or SNMP – using the ◄ ► arrow
keys, then press ENTER.
If selecting CONFIG: Remote → Ethernet Config→Gateway:
Ethernet IP Gateway:
192.168.001.002 (◄ ► ▲ ▼)
Edit the IP Gateway Address for the Ethernet M&C port for this unit. Use the ◄ ► arrow
keys to first select the digit to edit, and then use the ▲▼ arrow keys to edit the value of
that digit. Press ENTER when done.
If selecting CONFIG: Remote → Ethernet Config→Address:
Ether IP Address/Range:
192.168.001.002/24(◄ ►,▲ ▼)
Edit the IP Address and Range for the Ethernet M&C port for this unit. Use the ◄ ► arrow
keys to first select the digit to edit, and then use the ▲▼ arrow keys to edit the value of
that digit. Press ENTER when done.
