CPA C-Band Indoor Solid State Power Amplifier
Revision 1
Connectors and Pinouts
MN/CPA-IN.IOM
3–9
3.3.6
J8 | 10/100 ETHERNET Connector
Chapter 6. ETHERNET-BASED REMOTE PRODUCT MANAGEMENT
This RJ-45 connector provides the CAT5 10/100 BaseT interface for remote
product management and data traffic exchange.
3.3.7
J9A | EXT REF IN / J9B | EXT REF OUT Connectors (OPTIONAL)
REF DES Name
Connector Type
Description
J9A
EXT REF IN
BNC
External Reference Input
J9B
EXT REF OUT BNC
External Reference Output
