Operators Manual
ALX 720
4/09 Page 88 Status messages
Problem Meaning How to solve
ST27 Number overflow (Auto-
Acknowledgement) Check whether numbers exceed 65000
or format positions exceeding maximum
label dimension are used
ST28 Character, line or logo do not fit
into the physical printing format
(Auto-Acknowledgement)
Characters fitting perfectly into the
printing format are printed only
Change positions accordingly
ST29 Logo number already existing
(Auto-Acknowledgement)
Former logo is not overwritten
First clear former logo, or use another
logo number
ST30 Logo too large for logo buffer or
format storage (Auto-
Acknowledgement)
ST31 Logo number not within address
area (inadmissible logo number)
(Auto-Acknowledgement) Check whether number smaller than 0 or
greater than 255
Check whether selected logo number is
occupied
ST32 Characters, lines, blocks are
positioned in area limited by the
adjusted Batch Mode (Auto-
Acknowledgement) The position
will be shifted automatically in the
imprintable area Change parameter adjustment from
Batch mode to R1:1 or N1:1 mode
Correct field position accordingly to non
imprintable area.
ST33 EASY PLUG wrong command #PA
to #IM remove command
ST35 Logo is to big for the card memory
(Auto- Acknowledgement) use bigger card
ST36 card can not be found or
programmed use SRAM card and format as colour
card
check if card is write protected
ST39 EASY PLUG card speedo error use correct speedo command (see
EASY PLUG)
ST40 RS232 - Framing error Check parameter adjustments at printer
and computer: BAUD, SBIT
ST41 RS232 – Parity error Check parameter adjustments at printer
and computer: PARI
ST44 ID Matrix Barcode error Check command
