Page 113
Operators Manual
ALX 720
4/09
Page 113
Connections and signals
LED Über-/Unterspannung
Bereit LED
Übertemperatur 100% on
Überstrom 25% on / 75% off
Beides 75% on / 25% off
+ Takt
+ Richtung
- Richtung
- NC
+ NC
- Takt
Bereit Collector
Bereit Emitter
48VAC
48VAC
Phase1B
Phase1A
Phase2B
800 Schr
400 Schr
Schrittauflösung
Figure 33 Mounting diagram motor control board
JP1
Figure 34 Display jumper setting
