Operators Manual
ALX 720
4/09 Page 87 Status messages
Problem Meaning How to solve
ST10/11 Check -total error - RAM card Check whether correct RAM card
(spooler + logo) is plugged in
Reformat card Caution: All data are
cleared!
ST13 Barcode not to read • check scanner
• check print quality
ST15 Function of print head lifting is
interrupted Check whether head pressing leaver is
sticking by poll out, correct if necessary
ST17 Pressure lever is not closed check lever and close if open
ST20 Wrong immediate command (Auto-
Acknowledgement) Command is ignored
ST21 Wrong format command (between
#ER and #Q) (Auto-
Acknowledgement) Yet execution of print job
ST22 Format command without
introductory #ER (Auto-
Acknowledgement) Yet execution of print job
ST23 Invalid command ( Auto-
Acknowledgement) Command is ignored
ST24 RS232 Reception error >
Handshake Problem Switch off acoustic signal by means of
(NEXT) key
Acknowledge by (FEED) key display:
“OFF“ Job is activated, but characters
recognised as false are not used
Execute job by operation of (ON/OFF)
key or Clear job(s) in program „SCLR“
and transmit again
Check adjustments: BAUD, PARI, SBIT,
DBIT, HAND
Check for external influence
Check transmission line
ST25 Reception buffer overflow
• Interface is switched inactive
• Reception buffer is cleared Switch off acoustic signal by means of
(NEXT) key
Acknowledge by (ON/OFF) or (FF) key
display: “OFF“
Check transmission synchronisation (
„HAND“) Summery of Parameters and
Info Printouts
ST26 Inadmissible size or printing offset
to gap (Auto-Acknowledgement) Size of last format or last printing offset
is kept
