Operation Sorensen SLM-Series DC Load
3-10 M540071-01 Rev C
Set Vsense Mode
Set
LOAD OFF
Voltage
Set
LOAD On
Voltage
LIMIT
Set
G/NG Voltage
Limits
Set
G/NG Current
Limits
Set
G/NG Power
Limits
Any up/down button toggles
Auto / On
Set
Start Current for
OCP Test
Set
Range to Auto or
Range II
Any up/down button toggles
Auto / On
Set
Stop Current for
OCP Test
LED ON: V, LIMIT
Upper 5 Digit: Upper
Limit
Lower 5 Digit:: Lower
Limit
LED ON: W, LIMIT
Upper: Upper Limit
Setting
Lower: Lower Limit
Setting
LED ON: A, LIMIT
Upper 5 Digit: Upper
Limit
Lower 5 Digit:: Lower
Limit
LEDs ON: LIMIT
Upper: "SEnSE"
Lower: Auto / On
LEDs ON: V, LIMIT
Upper: Voltage Setting
Lower: "Ld-on"
LEDs ON: V, LIMIT
Upper: Voltage Setting
Lower: "Ld-oFF"
LEDs ON: LIMIT
Upper: "rAnGE"
Lower: AUto / rAn2
LEDs ON: A, LIMIT
Upper: "iStAr"
Lower: Current
Setting
LEDs ON: A, LIMIT
Upper: "iStOP"
Lower: Current
Setting
FUNCTION DISPLAY CONTROL
1
×Ø
Sets upper limit
↑↓ Sets lower limit
×Ø
Sets upper limit
↑↓ Sets lower limit
×Ø
Sets upper limit
↑↓ Sets lower limit
×Ø
↑↓ Coarse/fine setting
×Ø
↑↓ Coarse/fine setting
×Ø
↑↓ Coarse/fine setting
×Ø
↑↓ Coarse/fine setting
Coarse or fine up button: moves
from "nor" --> "OCP" --> "OPP"
Coarse or fine down button: moves
down from "OPP" --> "OCP"--> "nor"
Set
Start Power for
OPP Test
Set
Threshold Voltage for
OCP/OPP Tests
Set
Power Step Size
for OPP Test
Set
Stop Power for
OPP Test
LEDs ON: A, LIMIT
Upper: "iStEP"
Lower: Current
Setting
LEDs ON: W, LIMIT
Upper: "PStAr"
Lower: Power
Setting
LEDs ON: W, LIMIT
Upper: "PStOP"
Lower: Power
Setting
LEDs ON: W, LIMIT
Upper: "PStEP"
Lower: Power
Setting
Set
Test Mode
LEDs ON: LIMIT
Upper: ""
Lower: nor / OCP /
OPP
LIMIT
Is OCP or OPP
Test Selected
?
OCP mode: current stepped
test will be run
OPP mode: power stepped
test will be run
"nor" mode: normal mode, all
standard modes -- CC, CR,
CV, CP, Dynamic, Shorts --
will be run
Store Setup in
Chassis Memory
Load Module
Setup Complete
No
Yes
1. Press chassis "STORE" button.
2. Use Bank Up/down buttons and
State 1-5 buttons to store setup, per
SLM-4 or SLM-1 manual.
Load Module
Setup Complete
Set
Current Step Size
for OCP Test
LEDs ON: A, LIMIT
Upper: "iStEP"
Lower: Current
Setting
×Ø
↑↓ Coarse/fine setting
1
×Ø
↑↓ Coarse/fine setting
×Ø
↑↓ Coarse/fine setting
×Ø
↑↓ Coarse/fine setting
×Ø
↑↓ Coarse/fine setting
Figure 3-3 Flowchart for Load Module General Setup Parameters and OCP and OPP Tests
Press the LIMIT button to enter setup mode. To skip setup of any parameter, scroll past by
pressing the LIMIT key to advance to the next parameter. When setup is complete, press LIMIT key
until its LED is no longer lit.
(
indicates pressing LIMIT button to advance to next parameter).
