HDCVI Standalone DVR User’s Manual
220
Please refer to the following sheet for detailed information.
Parameter Function
Event
Type The abnormal events include: No disk, disk error, disk no space, net
disconnection, IP conflict and MAC conflict.
You can set one or more items here.
Less than: You can set the minimum percentage value here (For disk
not space only). The device can alarm when capacity is not sufficient.
You need to draw a circle to enable this function.
Enable Check the box here to enable selected function.
Alarm Out Please select corresponding alarm output channel when an alarm
occurs. You need to check the box to enable this function.
Latch The alarm output can delay for the specified time after an alarm stops.
The value ranges from 1s to 300s.
Show
message System can pop up a message to alarm you in the local host screen if
you enabled this function.
Alarm
upload System can upload the alarm signal to the centre (Including alarm
centre.
Send
Email If you enabled this function, System can send out an email to alert you
when an alarm occurs.
Buzzer Check the box here to enable this function. The buzzer beeps when an
alarm occurs.
Log Check the box here, system can record the network event alarm log.
5.8.4 Storage
5.8.4.1 Schedule
In this interfaces, you can add or remove the schedule record setup. See Figure 5-75.
There are three record modes: general (auto), motion detect and alarm. There are six
periods in one day.
You can view the current time period setup from the color bar.
 Green color stands for the general record/snapshot.
 Yellow color stands for the motion detect record/snapshot.
 Red color stands for the alarm record/snapshot.
 Blue color stands for MD&alarm record/snapshot.
 Orange color stands for intelligent record/snapshot.
