Viewing and Analyzing Results
Optical Modulation Analyzer 65
Using Pattern Masks
The following standard masks are provided with the application:
Note: When an acquisition file contains masks, you can view their settings in the
Current Acquisition Information window.
Activating and Displaying Masks
When masks are activated, measurement tables can include hit test results
(hit counts and hit ratios). Values are computed the same way as BER/SER
(one per polarization, total and per burst). See how to display these results
or not in Using the Measurement Tables on page 56.
Note: Masks are not available when Averaging is active and cannot be applied on
averaged data.
IEEE G.802.3ba ITU G.959.1 Other
40-100 LR (large ratio) NRZ 10G 1310 nm RZ 40G custom
40-100 SR (small ratio) NRZ 10G 1550 nm
NRZ 40G
