Post-Processing and Reanalyzing Data
Optical Modulation Analyzer 115
Reanalyzing Acquisitions with New Settings
Reanalyzing Acquisitions with New Settings
You can see the effect of applying new settings on previously acquired data
with the Reanalyze feature. You can use this feature on the PSO-200 Optical
Modulation Analyzer or with a file opened on a separate computer.
Most acquisition and analysis settings can be modified, but not those
related to the input signal itself. Unavailable settings are grayed out in the
application.
Masks and Gearbox settings contained in the original file will be discarded.
Note: You can undo your changes at any time as explained in Reverting to
Original File on page 116.
To reanalyze acquisition data:
1. From the File menu, select Reanalyze.
2. Under all tabs, select the new settings.
3. Click Analyze to confirm your settings and start the process. This will
take a few seconds.
4. Save the acquisition in a new file or export the data as needed (see
Exporting Data on page 113).
