SCPI Commands Reference
Optical Modulation Analyzer 207
Product-Specific Commands—Description
:MMEMory:STORe:GEARbox:STReam
Description This command sets the GearBox Stream
Alignment Setup(string modulation, string
gearboxLayout, string fileDestination).
This command is not associated with the *RST
value.
Syntax :MMEMory:STORe:GEARbox:STReam16
QAM|APSK|BPSK|DP-16QAM|DP-APSK|DP-BPS
K|DP-OOK|DP-QPSK|OOK|QPSK,OneGlobalStr
eam|DualXYStreams|nIndividualStreams,
ame>
Parameter(s)

modulation:
The program data syntax for the first parameter is
defined as a
element. The allowed
DATA> elements for this parameter are:
16QAM|APSK|BPSK|DP-16QAM|DP-APSK|DP-B
PSK|DP-OOK|DP-QPSK|OOK|QPSK.
Sets the string modulation format for the
GearBox Stream Alignment Setup.
16QAM , selects 16QAM as the string modulation
format for the GearBox Stream Alignment Setup.
APSK, selects APSK as the string modulation
format for the GearBox Stream Alignment Setup.
BPSK, selects BPSK as the string modulation
format for the GearBox Stream Alignment Setup.
DP-16QAM , selects 16QAM as the string
modulation format for the GearBox Stream
Alignment Setup.
