EXFO PSO-200 Optical Modulation Analyzer User Manual
Page 33
Setting Up the Optical Modulation Analyzer
Optical Modulation Analyzer
25
Using Special Modulation Modes
The figure below shows an example of intensity sampling of 42 GBd QPSK
data (top: intensity eye diagram; bottom: corresponding 127 bit pattern).
The intermediate frequency recovery algorithm is bypassed so that only
intensity is sampled. The phase information is not retrieved.
