6
Customizing the Graph and
Data Layout
Selecting and Customizing the Layout
The application’s main window is fully customizable. You can start with
one of the preset single- or dual-polarization layouts that may already suit
your needs. Each layout contains a set of graphs and tables.
Note: Predefined layouts are not editable. Once you close a tab, you can only
make it appear again by re-selecting a layout that contains it.
Note: Dual-polarization layouts are available even if your unit does not support it,
allowing you to open files previously acquired on other units. Polarizations
are identified by X and Y.
Split bars
