Optical Modulation Analyzer
131
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
GENERAL SPECIFICATIONS
Weight
23 kg (51 lb)
Size (H x W x D)
288 mm x 439 mm x 380 mm
(11
5
/
16
in x 17
5
/
16
in x 14
5
/
16
in)
Temperature
operating
0
o
C to 35
o
C (32
o
F to 95
o
F)
Relative humidity
80 % non-condensing
SAFETY
21 CFR 1040.10 and IEC 60825-1:2007
CLASS 1 LASER PRODUCT
N
SPECIFICATIONS
a
Optical
Wavelength range
1530 nm to 1565 nm (C band)
Line-coding schemes
OOK, BPSK, PSK, QPSK, DPSK, DQPSK, APSK and 16-QAM, as well as all dual-polarization,
RZ or NRZ versions of these schemes
Transmission rates
Transmission rate independent; any rate up to 75 GBd (gigabaud)
Pattern length supported
< 2
16
(including PRBS) in Pattern mode
Unlimited (random data) in Constellation or Eye mode
Sensitivity
–13 dBm
User interfaces
Display
15.4 in TFT touchscreen
Ports
LAN and USB (3)
Operating system
Windows 7
™
