Viewing and Analyzing Results
Optical Modulation Analyzer 51
Playing Back Acquisition Files
Playing Back Acquisition Files
Once you have acquired bursts, or after opening a previously saved file,
you can use the playback buttons to see the behavior of the acquired
signal. All bursts will be played at the same speed as when acquired.
You can also find the playback controls in the Playback menu.
Note: While playing back, the burst number (with its date and time) and total
burst count are displayed in the status bar.
You can set the playback to either stop at the end of the sequence, or loop
back to the first frame and continue until you press the Stop button.
To set the playback to loop:
1. From the Settings menu, select General.
2. Select the General tab.
3. Under Playback, select the Play in loop option.
4. Click Apply to confirm your settings, or OK to also close the window.
Move forward to the next frame
Move back to the
previous frame
Start playback
Pause playback
Stop playback and
return to first frame
Move to the end of
the sequence
