EXFO FTB -5240S/5240BP Optical Spectrum Analyzer for FTB 500 (NS-1434) User Manual
Page 92
Setting Up the Instrument in WDM Mode
84
FTB-5240S/5240BP
Setting Up WDM Analysis Parameters
2. Select the Channels tab.
3. Press Import from Trace. All peaks from the current trace will be
added to the channel list.
A warning message will be displayed if any channels are overlapping. Press
OK to close the warning window.
Note: Changes can be applied to any channel at any time.
Note: If some channels were already present in the channel list, the new
channels created with the Add Current Peaks button will be added to the
list.
