Optical Spectrum Analyzer
7
3
Getting Started with Your
Optical Spectrum Analyzer
Inserting and Removing Test Modules
To insert a module into the FTB-500:
1. Exit ToolBox and turn off your unit.
2. Position the FTB-500 so that its right panel is facing you.
C
AUTION
Never insert or remove a module while the FTB-500 is turned on.
This will result in immediate and irreparable damage to both the
module and unit.
W
ARNING
When the laser safety LED (
) is flashing on the FTB-500, at least
one of your modules is emitting an optical signal. Please check all
modules, as it might not be the one you are currently using.
