Mportant – EXFO FTB -5240S/5240BP Optical Spectrum Analyzer for FTB 500 (NS-1434) User Manual
Page 21
Getting Started with Your Optical Spectrum Analyzer
Optical Spectrum Analyzer
13
Starting the Optical Spectrum Analyzer Application
The main window (shown below) contains all the commands required to
control the Optical Spectrum Analyzer:
I
MPORTANT
For optimal test results, you must allow a minimum warm up
period of two hours for your Optical Spectrum Analyzer before
starting your tests.
Display
panes
Result
panes
Function
buttons
