58 Operations
Trigger out
DI_SW O ● ● ● ● ● ● ● ●
DO_SW O ● ● ● ● ● ● ● ●
Event
PM O ● ● ● ● ● ● ● ●
COS O ● ● ● ● ● ● ● ●
Handshake
DI-REQ I ● ● ● ● ● ● ● ●
DI-ACK O ● ● ● ● ● ● ● ●
DI-TRIG I ● ● ● ● ● ● ● ●
DO-REQ O ● ● ● ● ● ● ● ●
DO-ACK I ● ● ● ● ● ● ● ●
DO-TRIG I ● ● ● ● ● ● ● ●
Clock
DO-SCLK I/O ●
DI-SCLK I/O ●
Function Signal I/O Description
I
2
C Master
SCL O
I
2
C Clock– I
2
C clock signal to slave
device capable of clock rate up to
1953.125KHz.
SDA I/O I
2
C Serial Data– Data signal for I
2
C read/
write communication.
SPI Master
SCK O
SPI Clock– SPI clock signal to slave
device capable of clock rate up to
62.5MHz.
SDI I
Master Input Slave Output– Data signal
for SPI read communication.
SDO O
Master Output Slave Input– Data signal
for SPI write communication.
CS_0 O
Chip Select of Slave Device 0– Output
signal to select the desired SPI slave
device 0.
Function Signal I/O AFI0 AFI1 AFI2 AFI3 AFI4 AFI5 AFI6 AFI7
