Introduction 17
PCIe-7360
Table 1-3: SMB Jack Connector Signal Description
1.7 LED indicator
The LED on the faceplate indicates I2C & SPI communication and
digital I/O status of the PCIe-7360.
Table 1-4: LED indicator
Signal
Signal
Type
Direction Description
CLK IN Clock I
External clock input for DI/DO sampled
clock from external device to the
PCIe-7360
CLK OUT Clock O
DI/DO sampled clock exporting from the
PCIe-7360 to an external device
LED Color Mode
ACC
(Access)
Red DI DMA operation
Green DO DMA operation
Amber DI & DO DMA operation
