Delta Electronics AC Motor Drive VFD007S23A User Manual
Page 89
Chapter 5 Parameters|VFD-S Series
5-34
Revision August 2006, SE08, SW V2.61
Setting
Function
Description
d10
PLC Program Running
the output will be activated when the PLC program is
running.
d11
PLC Program Step
Completed
the output will be activated for 0.5 sec. when each multi-
step speed is attained.
d12
PLC Program Completed
the output will be activated for 0.5 sec. when the PLC
program cycle has completed.
d13
PLC Operation Paused
the output will be activated when PLC operation is
paused.
d14
Terminal Count Value
Attained
counter reaches Terminal Count Value.
d15
Preliminary Counter Value
Attained
counter reaches Preliminary Count Value.
d16
AC Motor Drive Ready
d17
FWD Command Indication
When AC drive receives the command of forward
running, it will output immediately no matter AC drive is
in the state of run or stop.
d18
REV Command Indication
When AC drive receives the command of reverse
running, it will output immediately no matter AC drive is
in the state of run or stop.
