13.2.2. Changing the ID display position for arbitrary camera position using the pattern function
All ID display positions can be preset and stored in 10 different patterns (1–10). All ID display positions can be
changed by selecting one of the 10 patterns at each individual position.
1. On the Camera Setting screen for individual position, select
“LOCATION” with the joystick, then press the Set key.
2. Select “COMMON” or “PATTERN1 – 10” with the joystick, then
press the Set key.
3. Select the item to be changed with the joystick, then press the
Set key.
Note
Setting procedures and option contents are the same as those
of “Camera Settings.”
P O S 1
I M A G E
L O C A T I O N
*
C A M E R A P O S
*
C O M M O N
P R E S E T M E M O R Y
P A T T E R N 1
Camera Setting screen for individual position
*
P A T T E R N 1
*
A D D R E S S
C A M E R A
P O S I T I O N
T O U R
H O M E
A L A R M
S E C T O R
N E X T P A G E
Pattern setting screen
13.2. Changing Picture Quality and ID Display Positions for Individual camera position
13.2.1. Changing the picture quality for arbitrary camera position using the scene function
Such picture quality settings as white balance, backlight compensation, brightness, day & night, shutter
speed, AGC, slow shutter, enhancer, and chroma can be preset and stored for up to 10 different scenes
(1–10). Picture quality can be changed by selecting one of the preset 10 scenes at each individual position.
1. On the Camera Setting screen for individual position, select
“IMAGE” with the joystick, then press the Set key.
2. Select “COMMON” or “SCENE1 – 10” with the joystick, then
press the Set key.
3. Select the item to be changed with the joystick, then press the
Set key.
Note
Setting procedures and option contents are the same as those
of “Camera Settings.”
P O S 1
I M A G E
L O C A T I O N
*
C A M E R A P O S
*
C O M M O N
P R E S E T M E M O R Y
P A T T E R N 1
Camera Setting screen for individual position
- - -
- - -
-
*
- -
- - - -
*
*
S C E N E 1
*
W . B .
B A C K L I G H T
D A Y / N I G H T
A G C
S L O W S H U T T E R
S H U T T E R S P E E D
E N H A N C E R
B R I G H T N E S S
A T W R
B
O F F
N O R M A L
A U T O
X 3 2
C H R O M A
N O R M A L
-
*
- -
- -
-
-
-
*
-
- - - -
-
+
+
+
Scene setting screen
