9. CONTACT OUTPUT SETTINGS
Camera built-in contact outputs can be controlled by the controller.
9.1. AUX1 Setting
The AUX1 is an open collector type contact. The controller’s auxiliary switch is used to control it.
1. Select “AUX” on the Camera Menu screen, then press the Set
key.
2. Select “AUX1” on the AUX (Contact Output Setting) screen,
then press the Set key.
3. Select “INITIAL STATE” on AUX1 Setting screen, then press
the Set key.
4. Select “ON” or “OFF” with the joystick, then press the Set key.
When the initializing operation has been terminated after the
power had been turned on, set the AUX1 to ON (valid) or OFF
(invalid).
5. Select “ON STATE” on the AUX1 Setting screen, then press
the Set key.
6. Select “CLOSE” or “OPEN” with the joystick, then press the
Set key.
Set the contact whether to Close or Open when it is turned
ON.
7. Do not change setting of “TYPE” on the AUX1 Setting screen.
Note
Do not set types other than Momentary (factory default). If changed, AUX1 does not operate correctly.
8. Select “ON TIME” on the AUX1 Setting screen, then press the Set key.
9. Select “NO LIMIT,” “1sec,” “2sec,” “3sec,” “5sec,” “10sec,” “20sec,”or “30sec” with the joystick, then press
the Set key to set the duration that the contact is maintained ON.
NO LIMIT:
Maintained to be ON until it is turned OFF
“1sec,” “2sec,” “3sec,” “5sec,” “10sec,” “20sec,” “30sec”:
Contact is maintained ON for the preset duration.
C A M
C A M E R A M E N U
P R E S E T
I D S E T T I N G
C A M E R A S E T T I N G
A U T O M O D E
A L A R M
A U X
T I M E R
M A N U A L
M A I N T E N A N C E
Camera menu screen
