11.3. Rotation Limit Setting
Set the pan and tilt rotation range.
1. Select “P/T LIMIT SETTING” on the Manual Setting screen,
then press the Set key.
2. Select “LEFT,” “RIGHT,” “UP,” or “DOWN” with the joystick,
then press the Set key.
The direction of rotation range is then set.
3. Tilt the joystick left or right to set the limit orientation to “LEFT”
or “RIGHT” and upward or downward to set “UP” or “DOWN”,
then press the Set key.
4. Repeat Step 2, 3 to perform settings for all directions.
The rotation limit is set.
Z O O M S C A L A B L E P / T
M A X P / T S P E E D
P / T L I M I T S E T T I N G
*
M A N U A L
*
P / T L I M I T
F L I P
U P L I M I T
1 2 0
O F F
O N
O F F
L E F T
O N
Manual setting screen
P / T L I M I T S E T T I N G
* * * -
L E F T
Rotation limit (left) setting screen
11.4. Manual Speed Setting
Set the maximum speed of panning and tilt in manual operation.
1. Select “MAX P/T SPEED” on the Manual Setting screen, then
press the Set key.
2. Select “A,” “8,” “16,” “24,” “40,” “60,” “90,” “120,” “160,” “240,”
or “360”, then press the Set key.
Pressing the Set key sets the maximum speed in manual
operation.
Note
The larger the figure is, the faster pan and tilt speeds.
“A” : Operates at a constant speed of “25” without acceleration
or deceleration.
Z O O M S C A L A B L E P / T
M A X P / T S P E E D
P / T L I M I T S E T T I N G
*
M A N U A L
*
P / T L I M I T
F L I P
U P L I M I T
1 2 0
O F F
O N
O F F
L E F T
O N
Manual setting screen
