5.4. ID Display Position Settings
5.4.1. Setting the common title display position and its length
Set the title display position and its length common to all camera positions. It is also possible to set the title
display position and its length (pattern settings) individually for each camera position. When setting the display
position, each “Display” ID on the ID setting screen must be set to ON.
1. With the joystick, select “LOCATION” on the ID setting screen
and press the Set key.
2. Select each setting item with the joystick and perform its
settings.
ID display position setting screen
*
L O C A T I O N S E T T I N G
*
A D D R E S S
C A M E R A
P O S I T I O N
T O U R
H O M E
A L A R M
S E C T O R
N E X T P A G E
[ Setting the ID display positions for the address, angle, zoom, date, and time ]
1. With the joystick, select each ID location setting item for ID
display position settings and press the Set key.
The arrow
is displayed at the selected ID on the ID
display position setting screen.
2. Use the joystick to select each setting item and perform its
settings.
Note
When the selected title coincides with another title, the
selected title takes precedence, causing the other title to be
moved so as not to coincide with the selected title.
( )
Position setting screen
Example when “Address
* * *
is selected”
A D D R
* * *
A M E R A I D
P O S I T I O N
H O M E I D 2
*
H O M E I D 3
*
T O U R I D
* *
M M / D D / Y Y
* * : * *
A M
Z O O
S E C T O R I D
A L A R M I D
*
H O M E I D 1
*
A U X I D
* * *
* * * / * * *
