Motion detection area setting screen
12.8.1. Detection area setting
Set locations for motion detection sensors.
1. On the Maintenance screen, select “MOTION DETECTION”,
then press the Set key.
2. Select “1POS,” “2POS,” “254POS,” or “255POS” with the
joystick, then press the Set key.
3. On the Motion Detect Setting screen, select “FUNCTION”,
then press the Set key.
4. Select “ON” with the joystick, then press the Set key.
5. On the Motion Detection Area Setting screen, select the area
number to be detected, then press the Set key.
6. Select “OFF,” “ON – L,” “ON – M,” or “ON – H”, with the joystick,
then press the Set key.
OFF:
No movement detected.
ON – L: Detects movement at low sensitivity.
ON – M: Detects movement at intermediate sensitivity.
ON –H: Detects movement at high sensitivity.
7. If the detection area (a semi-transparent, blue rectangle) is
displayed, select the desired detection area with the joystick,
then press the Set key. The detection area is then set.
8. Select “CHECK” under area number selection conditions, then
press the Set key.
The area number is displayed in the set area.
Conduct the test to see if the set area can be detected as
intended. If detected, a semi-transparent, blue rectangle is
displayed in the detection area.
9. Press the Set key.
A transparent, blue rectangle is displayed to indicate that the
setting has been confirmed.
