854 Sprayer Control
To exit the Memory Feature if no changes were made
or after clearing a value:
• Press and hold the MEMORY key for three
seconds.
Figure 7-3: Saving Information to Memory
MEM
2645
TOT
Vol
Tank.Feature
Auto Tank Filling
NOTE: The Auto Tank Fill Feature can only be used
if “FILL VALVE” was selected in the Digital
Out #2 step of OEM Programming.
• Turn the Master Boom Switch to the “Off”
position.
• Press the TANK key.
• Use the PLUS or MINUS keys to enter
the volume to be added to the tank, OR
• Press the AUTO/MAN key to set the volume
to the maximum tank content.
• Press the PROGRAM key to activate the
procedure.
• Turn the Master Boom Switch to the “On”
position to activate the Fill Valve (switch).
The tank will begin filling and the console will measure
the volume. If it is necessary to stop the filling process
for any reason, turn off the Master Boom Switch.
Once the console has reached the volume to be filled,
it will automatically turn the valve off.
• Once the process is complete, turn the Master
Boom Switch “Off”.
• Press and hold the TANK key for three
seconds to return to normal operating mode.
Figure 7-4: Auto Tank Filling
1000
FiL
1000
FiL
Off
1000
FiL
On
