854 Sprayer Control
To access the Application Preset Setup Mode, the
Master Switch must be in the “Off” position.
• Press the PRESET key to display the
current presets being used.
• Press the PRESET key again within 3
seconds to advance to the next preset. This
process can be continued throughout all 5
presets.
• To program a particular preset, press the
PROGRAM key while that preset is
displayed.
Figure 5-1: Application Preset Setup
15.0 PST
-2-
EXAMPLE: To program present #2, press the
PRESET key until “PST - 2 - “ is
displayed. Press the PROGRAM key to
program the value.
Tip.Spacing
Enter the spacing between the spray nozzles in
inches (cm).
• Use the PLUS or MINUS keys to adjust
the value.
• Press the PROGRAM key to advance to the
next step
Figure 5-2: Tip Spacing
20
-2-
CHAPTER 4 - APPLICATION PRESET SETUP MODE
