28
854 Sprayer Control
Figure 4-37: Communicating with Laptop/Fieldware
PC
Logging Information to a Laptop running
Logging Software
• Connect the laptop to the 854 console using a
45-20063 serial cable.
• Select “LOG” in the Communications Setup
step.
• The LOG mode is an advanced data transfer
tool used with specially configured hardware
devices only. This mode is not used during
normal applications.
Figure 4-38: Log Mode
LO6
GPS.Speed
NOTE: The GPS Speed option is only available
when “PC” is selected during the
Communications Setup.
GPS Speed allows the 854 to accept speed data
from an external GPS source. Select either “On” to
use the external GPS Speed input, or “Off” to ignore
external speed input.
• Use the PLUS or MINUS keys to adjust
the value to either “On” or “Off”.
• Press the PROGRAM key to advance to the
Use External Rate step.
Figure 4-39: GPS Speed Simulation
On
6PS SPed
Use.External.Rate
NOTE: The External Rate option is only
available when “PC” is selected during
the Communications Setup. This option
is typically used with an external GIS
computer, such as the Legacy 6000.
External Rate is used to indicate whether local
control rates are to be used or ignored. When set
to “Off”, the 854 console will ignore the rate coming
from the external computer and use its own preset
rate. When set to “On”, the 854 will use the rate
determined by the external computer (Legacy 6000),
usually as determined from a prescription map.
• Use the PLUS or MINUS keys to adjust
the value to either “On” or “Off”.
• Press the PROGRAM key to advance to the
Simulated Ground Speed step.
