SilentKnight SK-5208 Conventional FACP 10-30 Zone - Manual (Page 42)

151204
4-1
Section 4
Programming
The SK-5208 control panel can be programmed from either the on-board annunciator or the SK-5235 remote
annunciator. You must be in Programming Mode to program the control panel.
4.1 Keypad Operation During Programming
This section describes the function of the buttons on the keypad while in program mode.
Operation/Button Operation/Description
Enter Step Programming
mode Press 2, 7, ENTER, followed by installer level code (the factory programmed code is 123456
or 5208). See Section 4.2.6 for user code programming information.
Moving through
programming When you have entered programming correctly, the display will show Zone 1 Options. Press
to move to next programming option. See Table 4-4 for list of programming options
(column 1) and their menu items (column 2).
When the display shows the option you wish to program press ENTER to program items in
this option.
If you receive a trouble beep and the message TRY AGAIN appears you are not using an
installer level code.
Exit Step Programming Press RESET. You are prompted to save programming changes. The default is No. Press the
up or down arrow to select Yes to save programming changes. Press Enter to complete the
save and return to normal operation mode.
Down Arrow
Accepts the entered data and scrolls down to the next menu item.
Enter Button
Accepts the entered data and scrolls down to the next menu item.
Left Arrow
Scrolls backwards through the programmable items list for the currently selected option.
Right Arrow
Scrolls forward through the programmable options list or choices for an the selected item.
Silence Button
Enables extended programming list so you can scroll through lists of items that have multiple
components such as, Zone 1 -30. See Section 4.1.2 for an example.
Up Arrow
Accepts the entered data and scrolls up to the next menu item.
* Button
Used as shift key when entering special characters (A, B, C, D, or E characters). See Section
4.1.1 for more information.
# Button
Clear entry.
#
