Form P-MAPS III&IV, PN 262958R5, Page 8
Code 1A - Phase Loss/Voltage
Monitor, 208/230/460V - P/N
176826; 575V - P/N 58881
Code 10 -
Unit-Mounted
Digital
Controller
Display,
P/N 222189
Code 11 -
Programmed
IQ Digital
Controller
(unique
programming
determined
by Model and
Serial No.) -
P/N 257604
Code 12 - Control
Expansion Board (Opt
BHB6), P/N 222188
Code 13 - Plug-
in Card with
LON Software
(Option BHB5),
P/N 258413
Code 14 - Air
Proving Switch,
P/N 234712
Code 16 - Interface
Board (part of Option
AUR1), P/N 222769
Code 17 - Power
Supply (part of Option
Cabinet
Size
Heat
Section Size
Gas
Setpoint
Off
Label
Color
Switch
P/N
A 100, 150, 200
Natural &
Propane
0.80 Gray 197078
B
250 and
JHUP-250
Natural 0.80 Gray 197078
Propane 1.05 Brown
201160
300
Natural &
Propane
1.05 Brown
C
400, 500
Natural
Gas
1.40 Red 201159
600, 700 2.00 White 234054
JHUP-300 0.50 Orange 196388
D - All sizes prior to 8/11* 2.00 White 234054
D -
*Units
mfgd
beginning
8/11
(Serial
No.
Ignition
Code 96)
500 1.05 Brown 201160
600 1.40 Red 201159
700 1.05 Brown 201160
800 1.40 Red 201159
1000
Modulating 1.05 Brown 201160
Non-Modulating 2.00 White 234054
1200
Modulating 1.40 Red 201159
Non-Modulating 2.00 White 234054
1400
Modulating 1.05 Brown 201160
Non-Modulating 2.00 White 234054
1600
Modulating 1.40 Red 201159
Non-Modulating 2.50 White 222860
Code 18 -
Combustion
Air Proving
Switch
- RDCB
& RDDB
Gas Heat
Sections
Code 19 - Sequencer
for electric heat, gas
heat with in-curb
furnace JHUP 250 or
300, or D Cabinet with
two gas heat sections
Cabinet /
Location
Gas Heat
Section
Size
P/N
A - Low
Voltage
Panel
100
195641 150
200
B - Low
Voltage
Panel
250
195642 JHUP 250
300
C - on the
venter
motor
(pages
32-33)
400
195643
500
600
700
JHUP 300
D - on the
venter
motor
(page
34) or
the heat
section
control
panel
500
259476
600
700
800
1000
1200
1400
1600
Code 20 - Venter
Motor Capacitor -
by Gas
Heat
Section
Size
Control Board(s) for
Gas Heat Sections
Code 22 -
ID Plug P/N
ID Plug
No.
ID Plug
Label
Applies to
Cabinet Heat Sizes Ignition Code Gas
258113 13 MAPS A100NG
A
100
(In the Serial
No. - See
page 2.)
97
Natural
258114 14 MAPS A100LP Propane
258115 15 MAPS A150NG
150
Natural
258116 16 MAPS A150LP Propane
258117 17 MAPS A200NG
200
Natural
258118 18 MAPS A200LP Propane
258129 29 MAPS B250NG
B
250
Natural
258130 30 MAPS B250LP Propane
258131 31 MAPS B300NG
300
Natural
258132 32 MAPS B300LP Propane
258133 33 MAPS C400NG
C
400
96
Natural
258134 34 MAPS C500NG 500 Natural
258135 35 MAPS C600NG 600 Natural
258140 40 MAPS C700NG 700 Natural
258141 41 MAPS D500NG
D
500 & 1000 Natural
258142 42 MAPS D600NG 600 & 1200 Natural
258143 43 MAPS D700NG 700 & 1400 Natural
258144 44 MAPS D800NG 800 & 1600 Natural
These boards have a removable plug that is
unique by Size and gas. If the board is replaced,
the plug must be re-used or replaced; see below.
D Cab
Heat
Section
Size
Obsolete
Board
P/N (not
available)
Code 23 -
DSI Board
on 2nd Heat
Section
Serial No.
Ignition
Code
(page 2)
500 223554* -- 86
600 223555* -- 87
700 223556* -- 88
800 222678* -- 89
1000 223554* 195573 90
1200 223555* 195573 91
1400 223556* 195573 92
1600 222678* 195573 93
Code 23 - DSI Board on ALL
Cabinet D w/2 Heat Sections
(On non-modulating burner of
Sizes 1000, 1200, 1400 & 1600),
P/N 195573
Code 22 - ID
Plug (see below)
Code 1 B -
Socket for Code
1A monitors -
P/N 194168
Ilustrations of some Control Components (Refer to location on page 5 or 6.)
BE16),
P/N
256654
*Was used as a
special prior to
8/11. Check the
Serial No. ignition
code (see page 2).
Code 6 - Digital Controller
for MAPS ® IV Compressors,
P/N 266067
NOTE: Boards
without ID plugs
(right) used on
MAPS ® Cabinet
D mfgd prior to
08/11 are no longer
available. Contact your distributor or the
factory for replacement information.
CODE 21 - Ignition Control Board for
MAPS ® III&IV with Gas Heat
Cabinet
Size
Reznor ®
P/N
Mfr’s No.
Serial No.
Code
A & B 258319 VB1200-RZNR-AB 97
C 257246 VB1200 96
D* 257246 VB1200 96
*Beginning in 8/2011. For previously used boards without ID
plugs, see note and ignition codes on the right.
