Form P-MAPS III&IV, PN 262958R5, Page 11
CODE 70 - Motor Frame
Size
Reznor ®
P/N
Volt ph
Code 72A - Starter
(AN10, EN10, SN10)
Code 72B - Starter Overload
Type Opt HP fla Mfr’s No. Mfr’s No. P/N min max GE # P/N
TEFC
AL21
EL21
1/2 2.3 AO-H274 H56 16077 208 3 CL00A310T-1 151275 1.80 2.70 RTA1-J 151189
TEFC 1/2 2.0 AO-H274 H56 16077 240 3 CL00A310T-1 151275 1.80 2.70 RTA1-J 151189
TEFC 1/2 1.0 AO-H274 H56 16077 480 3 CL00A310T-1 151275 0.65 1.10 RTA1-F 151186
TEFC 1/2 0.7 AO-H276 J56 105568 575 3 CL00A310T-1 151275 0.65 1.10 RTA1-F 151186
TEFC
AL22
EL22
3/4 2.0 AO-H580 KA56 20371 208 3 CL00A310T-1 151275 1.80 2.70 RTA1-J 151189
TEFC 3/4 2.2 AO-H580 KA56 20371 240 3 CL00A310T-1 151275 1.80 2.70 RTA1-J 151189
TEFC 3/4 1.1 AO-H580 KA56 20371 480 3 CL00A310T-1 151275 1.00 1.50 RTA1-G 151187
TEFC 3/4 0.8 AO-H461 L56 105569 575 3 CL00A310T-1 151275 0.65 1.10 RTA1-F 151186
TEFC
AL23
EL23
SL23
1 3.3 WEG-00118E D56 *271444 208 3 CL00A310T-1 151275 2.50 4.10 RTA1-K 151190
TEFC 1 3.1 WEG-00118E D56 *271444 240 3 CL00A310T-1 151275 2.50 4.10 RTA1-K 151190
TEFC 1 1.6 WEG-00118E D56 *271444 480 3 CL00A310T-1 151275 1.30 1.90 RTA1-H 151188
TEFC 1 1.4 AO-H525 H56 105570 575 3 CL00A310T-1 151275 1.00 1.50 RTA1-G 151187
TEFC
AL24
EL24
SL24
1.5 4.8 WEG-00158E D56 *271445 208 3 CL00A310T-1 151275 4.00 6.30 RTA1-L 151191
TEFC 1.5 4.6 WEG-00158E D56 *271445 240 3 CL00A310T-1 151275 4.00 6.30 RTA1-L 151191
TEFC 1.5 2.3 WEG-00158E D56 *271445 480 3 CL00A310T-1 151275 1.80 2.70 RTA1-J 151189
TEFC 1.5 1.7 AO-T59027 M145T 105665 575 3 CL00A310T-1 151275 1.30 1.90 RTA1-H 151188
TEFC
AL25
EL25
SL25
2 6.1 WEST-NP0024 145T 158165 208 3 CL00A310T-1 151275 5.50 8.50 RTA1-M 151192
TEFC 2 5.6 WEST-NP0024 145T 158165 240 3 CL00A310T-1 151275 4.00 6.30 RTA1-L 151191
TEFC 2 2.8 WEST-NP0024 145T 158165 480 3 CL00A310T-1 151275 2.50 4.10 RTA1-K 151190
TEFC 2 2.2 AOS-T59028 145T 158166 575 3 CL00A310T-1 151275 1.90 2.70 RTA1-J 151189
TEFC
AL26
EL26
SL26
3 7.9 B-EM3559T 145T 159330 208 3 CL00A310T-1 151275 5.50 8.50 RTA1-N 151192
TEFC 3 7.2 B-EM3559T 145T 159330 240 3 CL00A310T-1 151275 5.50 8.50 RTA1-N 151192
TEFC 3 3.6 B-EM3559T 145T 159330 480 3 CL00A310T-1 151275 2.50 4.10 RTA1-K 151190
TEFC 3 2.8 B-EM3559T-5 145T **158168 575 3 CL00A310T-1 151275 2.50 4.10 RTA1-K 151190
TEFC
AL27
EL27
SL27
5 12.6 WEST-NP0052 184T 155048 208 3 CL02A310T-1 151277 10.00 16.00 RTA1-P 151194
TEFC 5 11.4 WEST-NP0052 184T 155048 240 3 CL01A310T-1 151276 10.00 16.00 RTA1-P 151194
TEFC 5 5.7 WEST-NP0052 184T 155048 480 3 CL00A310T-1 151275 4.00 6.30 RTA1-L 151191
TEFC 5 4.7 AOS-T59005 184T 158170 575 3 CL00A310T-1 151275 4.00 6.30 RTA1-L 151191
TEFC
AL32
7.5 19.5 WEST-NP7/54 213T 158171 208 3 CL04A310M-1 151279 17.50 22.00 RTA1-T 151197
TEFC 7.5 17.7 WEST-NP7/54 213T 158171 240 3 CL25A310T-1 151278 17.50 22.00 RTA1-T 151197
TEFC 7.5 8.9 WEST-NP7/54 213T 158171 480 3 CL00A310T-1 151275 8.00 12.00 RTA1-N 151193
TEFC 7.5 7.3 AOS-T59031 213T 158172 575 3 CL00A310T-1 151275 5.50 8.50 RTA1-M 151192
CODE 70 - Motor (cont’d) Frame
Size
Reznor ®
P/N
Volt ph Code 72A - Starter (cont’d)
Code 72B - Starter Overload
Type Opt HP fla Mfr’s No. Mfr’s No. P/N min max GE # P/N
Open
AL10
EL10
SL10
5 13.4 AO-196033J Y56HZ 113371 208 3 CL01A310T-1 151276 10.00 16.00 RTA1-P 151194
Open 5 13.2 AO-196033J Y56HZ 113371 240 3 CL01A310T-1 151276 10.00 16.00 RTA1-P 151194
Open 5 6.6 AO-196033J Y56HZ 113371 480 3 CL00A310T-1 151275 5.50 8.50 RTA1-M 151192
Open 5 5.4 AO-H956 Y56HZ 120020 575 3 CL00A310T-1 151275 4.00 6.30 RTA1-L 151191
Open
AL11
7.5 21.0 WEST DTP7/54 213T 105855 208 3 CL04A310M-1 151279 21.00 26.00 RTA1-U 151198
Open 7.5 19.0 WEST DTP7/54 213T 105855 240 3 CL25A310T-1 151278 17.50 22.00 RTA1-T 151197
Open 7.5 10.0 WEST DTP7/54 213T 105855 480 3 CL00A310T-1 151275 8.00 12.00 RTA1-N 151193
Open 7.5 7.5 AOS-E926 S213T 158164 575 3 CL00A310T-1 151275 5.50 8.50 RTA1-M 151192
Open
AL12
10 27.0 WEST DTP0104 215T 105858 208 3 CL04A310M-1 151279 25.00 32.00 RTA1-V 151199
Open 10 24.4 WEST DTP0104 215T 105858 240 3 CL04A310M-1 151279 25.00 32.00 RTA1-V 151199
Open 10 12.2 WEST DTP0104 215T 105858 480 3 CL01A310T-1 151276 10.00 16.00 RTA1-P 151194
Open 10 10.1 AOS-E925 S215T 158163 575 3 CL01A310T-1 151276 10.00 16.00 RTA1-P 151194
Open
AL15
15 40.3 WEST DTP0154 254T 142288 208 3 CL06A311M-1 203687 30.00 43.00 RTA2-E 151206
Open 15 36.4 WEST DTP0154 254T 142288 240 3 CL06A311M-1 203687 30.00 43.00 RTA2-E 151206
Open 15 18.2 WEST DTP0154 254T 142288 480 3 CL25A310T-1 151278 17.50 22.00 RTA1-T 151197
Open 15 16.0 B-EFM2513T-5-F2 254T 142289 575 3 CL02A310T-1 151277 14.50 18.00 RTA1-S 151196
Open
AL16
20 53.7 WEST DTP0204 256T 142296 208 3 CL07A311M-1 203793 54.00 65.00 RTA2-G 151202
Open 20 48.6 WEST DTP0204 256T 142296 240 3 CL07A311M-1 203793 42.00 55.00 RTA2-G 151202
Open 20 24.3 WEST DTP0204 256T 142296 480 3 CL04A310M-1 151279 25.00 32.00 RTA1-U 151198
Open 20 18.9 B-FM2515T-5-F2 256T 142297 575 3 CL25A310T-1 151278 17.50 22.00 RTA1-T 151197
Notes for TEFC Replacement Motors (below):
*Starter Required
*TEFC 1 HP, 208/230/480/3 phase - Replacement Motor
P/N 271444 requires a starter; consult the factory providing wiring
diagram or serial number to determine appropriate replacement starter and overload.
*TEFC 1.5 HP, 208/230/480/3 phase - Replacement Motor
P/N 271445 requires a starter; consult the factory providing wiring
diagram or serial number to determine appropriate replacement starter and overload.
**Shaft Size Change
** TEFC 3 HP, 575/3 phase - Replacement motor shaft size is 7/8” (original motor was 1-1/8”).
