Reznor MAPSIV RECC Parts Manuals - Manual (Page 37)

Form P-MAPS III&IV, PN 262958R5, Page 37
Fuse Panel Components by Voltage and Size
Heat Section
Voltage & Size Code
Description P/N
208V
or
240V
120
kW
327 Pressure Switch 197031
328 Fuse 250V (18) 207617
339 Transformer 75VA (2) 208989
330 Distribution Block (3) 223495
180
kW
327 Pressure Switch 197031
328 Fuse 250V (27) 207617
339 Transformer 75VA (2) 208989
330 Distribution Block 259881
480V
120
kW
327 Pressure Switch 197031
328 Fuse 600V (12) 207627
339 Transformer 75VA (2) 208989
330 Distribution Block (3) 222673
180
kW
327 Pressure Switch 197031
328 Fuse 600V (18) 207627
339 Transformer 75VA (2) 208989
330 Distribution Block (3) 223495
575V
120
kW
327 Pressure Switch 197031
328 Fuse 600V (12) 207627
339 Transformer 75VA (2) 258912
330 Distribution Block (3) 222673
180
kW
327 Pressure Switch 197031
328 Fuse 600V (18) 207627
339 Transformer 75VA (2) 258912
330 Distribution Block (3) 222673
Control Panel Components by Voltage and Size
Heat Section
Voltage & Size Code
Description P/N
208V
or
240V
120
kW
331 Sensing Tube Assy 111733
332
Contactor 25 Amp (2) 216386 (replaces 119625)
Contactor 50 Amp (5) 216388 (replaces 208375)
333 SCR Module 234057
334 A/D Converter (sequencer) 259224 (8 stage)
180
kW
331 Sensing Tube Assy 111733
332
Contactor 25 Amp (2) 216386 (replaces 119625)
Contactor 50 Amp (8) 216388 (replaces 208375)
333 SCR Module 234057
334 A/D Converter (sequencer) 259224 (8 stage); 259235 (2 stage)
480V
120
kW
331 Sensing Tube Assy 111733
332 Contactor 40 Amp (4) 216387 (replaces 223021)
333 SCR Module 220688
334 A/D Converter (sequencer) 222755 (4 stage)
180
kW
331 Sensing Tube Assy 111733
332 Contactor 50 Amp (6) 216387 (replaces 223021)
333 SCR Module 220688
334 A/D Converter (sequencer) 259224 (8 stage)
575V
120
kW
331 Sensing Tube Assy 111733
332 Contactor 40 Amp (4) 216387 (replaces 223021)
333 SCR Module 234058
334 A/D Converter (sequencer) 222755 (4 stage)
180
kW
331 Sensing Tube Assy 111733
332 Contactor 40 Amp (6) 216387 (replaces 223021)
333 SCR Module 234058
334 A/D Converter (sequencer) 222755 (4 stage)
Code 337 - Roof Curbs (Option listed for reference; when ordering, use P/N)
Roof Curb
Type
Cabinet
Size"
Models
Cooling
Sizes
Heating
Sizes
Same as
Option
PN
Same as
Option
P/N
without Energy
Recovery Module
with Energy
Recovery Module
Vertical
(Down)
Supply
A
RCB, RDB; RCC, RDC All Cooling Only
CJ31
205661
CJ34
262479
RECB, REDB; RECC, REDC All All Electric 205661 262479
RDCB, RDDB; RDCC, RDDC All -100 Gas 205660 262478
RDCB, RDDB; RDCC, RDDC All -150 Gas 205661 262479
RDCB, RDDB; RDCC, RDDC All -200 Gas 205662 262480
B
RCB, RDB; RCC, RDC All Cooling Only 205664 262482
RECB, REDB; RECC, REDC All All Electric 205664 262482
RDCB, RDDB; RDCC, RDDC All -250 Gas 205663 262481
RDCB, RDDB; RDCC, RDDC All -300 Gas 205664 262482
C
RCB, RDB; RCC, RDC
190, 216, 248,
262, 272, 288
Cooling Only 208854 262483
RCB, RDB; RCC, RDC
298, 410, 354,
370, 468, 482
Cooling Only 208856 262485
RDCB, RDDB; RDCC, RDDC All
-400 Gas 208854 262483
-500 Gas 208855 262484
-600 Gas 208856 262485
-700 Gas 208857 262486
RECB, REDB; RECC, REDC All All Electric 208856 262485
Horizontal
Supply
A
RCB, RDB; RCC, RDC All Cooling Only
CJ50
261699
CJ54
262533
RECB, REDB; RECC, REDC All All Electric 261699 262533
RDCB, RDDB; RDCC, RDDC All All Gas 261699 262533
B
RCB, RDB; RCC, RDC All Cooling Only 261700 262534
RECB, REDB; RECC, REDC All All Electric 261700 262534
RDCB & RDDB; RDCC, RDDC All All Gas 261700 262534
C
RCB, RDB; RCC, RDC All Cooling Only
CJ49
261701
CJ53
262535
RDCB, RDDB; RDCC, RDDC All All Gas 261701 262535
RECB, REDB; RECC, REDC All All Electric 261701 262535
Vertical
(Down)
Supply
D
RCB, RDB All Cooling Only
CJ3
223041
RECB, REDB All All Electric 223041
RDCB, RDDB All
-500 to -800 Gas 223041
-1000 to -1600 Gas 223042
D Cabinet Electric Components - Models RECB and REDB
