Reznor MAPSIV RECC Parts Manuals - Manual (Page 15)

Form P-MAPS III&IV, PN 262958R5, Page 15
Motor HP & Option AK Opt
Drive AM/EM/SM
Option
CODE 75 - Motor Pulley CODE 76 - Blower Pulley CODE 77 - Belt
(See Note for P/N’s.)
Serial No.
CODE (See
page 2.) HP AL/EL/SL (Voltage) (See Key, page 12.) P/N Model Bore P/N Model Bore
2
(cont’d)
25
(cont’d)
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
5, 6, 7 106748 1VL40 7/8
19111 AK 84 1 “A-section” 3.8 ft RJ
111862 AK 84 1-3/16 “A-section” 3.8 ft MK
8, 9, 10, 11, 12 106748 1VL40 7/8
18797 AK 64 1 “A-section” 3.8 ft SJ
208608 AK 64 1-3/16 “A-section” 3.8 ft NK
13, 14, 15, 16, 17
106748 1VL40
7/8
135200 AK 51 1 “A-section” 3.8 ft OK
106758 1VL44 208610 AK 56 1-3/16 “A-section” 3.8 ft PK
18, 19, 20, 21, 22, 23,
24, 25
106758 1VL44 7/8
206125 AK44 1 “A-section” 3.8 ft XJ
194295 AK 44H 1-3/16 “A-section” 3.8 ft QK
26, 27, 28, 29
106758 1VL44
7/8
135201 AK39 1 “A-section” 3.8 ft YJ
106748 1VL40 194296 AK 32 H 1-3/16 “A-section” 3.8 ft RK
3 26
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
9, 10, 11, 12 106748 1VL40 7/8
101414 BK130 1 “B-section” 3.8 ft UJ
208755 BK130H 1-3/16 “B-section” 3.8 ft SK
13, 14, 15, 16, 17 106748 1VL40 7/8
202654 BK105 1 “B-section” 3.8 ft VJ
208756 BK105H 1-3/16 “B-section” 3.8 ft RK
18, 19, 20, 21, 22 37451 1VM50 7/8
16153 AK104 1 “A-section” 3.8 ft YL
16154 AK104 1-3/16 “A-section” 3.8 ft OM
23, 24, 25, 26, 27,
28, 29
37451 1VM50 7/8
19111 AK84 1 “A-section” 3.8 ft PM
111862 AK84 1-3/16 “A-section” 3.8 ft QM
30, 31, 32, 33, 34,
35, 36
37451 1VM50 7/8
105483 AK69 1 “A-section” 3.8 ft RM
105484 AK71H 1-3/16 “A-section” 3.8 ft SM
5 27
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
9, 10, 11, 12 7963 2VP42 1 1/8
30621 2AK124 1 “A-section” 7.6 ft UM
223401 2AK124 1-3/16 “A-section” 7.6 ft VM
13, 14, 15, 16, 17 111681 1VP50 1 1/8
202652 AK124 1 “A-section” 3.8 ft YM
16156 AK124 1-3/16 “A-section” 3.8 ft WM
18, 19, 20, 21, 22 161444 1VP56 1 1/8
202652 AK124 1 “A-section” 3.8 ft YL
16156 AK124 1-3/16 “A-section” 3.8 ft OM
23, 24, 25, 26, 27,
28, 29
111681 1VP50 1 1/8
19111 AK84 1 “A-section” 3.8 ft PM
111862 AK84 1-3/16 “A-section” 3.8 ft QM
30, 31, 32, 33, 34,
35, 36
111681 1VP50 1 1/8
105483 AK69 1 “A-section” 3.8 ft RM
105484 AK71H 1-3/16 “A-section” 3.8 ft SM
7-1/2,
10
32, 33
C Cab only
prior to
7/2012
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
13, 14, 15, 16 164294 1VP71 1 3/8 208756 BK105H 1-3/16 BX70 - 92242 XK
17, 18, 19, 20 164294 1VP71 1 3/8 162836 BK90H 1-3/16 BX66 - 92240 YK
21, 22, 23, 24 164294 1VP71 1 3/8 112026 BK75H 1-3/16 BX64 - 114258 ZK
25, 26, 27, 28 164294 1VP71 1 3/8 208791 BK70H 1-3/16 BX63 - 92278 AL
32, 33
C Cab only
beginning
7/2012
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
13, 14, 15, 16 164294 1VP71 1 3/8 208756 BK105H 1-7/16 BX70 - 92242 AT
17, 18, 19, 20 164294 1VP71 1 3/8 162836 BK90H 1-7/16 BX66 - 92240 AU
21, 22, 23, 24 164294 1VP71 1 3/8 112026 BK75H 1-7/16 BX64 - 114258 AV
25, 26, 27, 28 164294 1VP71 1 3/8 208791 BK70H 1-7/16 BX63 - 92278 AX
32, 33
D Cab only
32” CL
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
13, 14, 15, 16 164294 1VP71 1 3/8 208756 BK105H 1-7/16 BX88 - 223420 DM
17, 18, 19, 20 164294 1VP71 1 3/8 162836 BK90H 1-7/16 BX86 - 223419 EM
21, 22, 23, 24 164294 1VP71 1 3/8 112026 BK75H 1-7/16 BX83 - 92333 FM
25, 26, 27, 28 164294 1VP71 1 3/8 208791 BK70H 1-7/16 BX83 - 92333 GM
15,
20
34, 35
D-cab only
32” CL
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
14, 15, 16, 17 113809 2VP71 1 5/8 89649 2BK100H 1-7/16 (2) BX88 - 223420 HM
18, 19, 20 113809 2VP71 1 5/8 113804 2BK90H 1-7/16 (2) BX86 - 223419 IM
21, 22, 23, 24, 25 113808 2VP75 1 5/8 89648 2BK80H 1-7/16 (2) BX85 - 92317 LM
26, 27, 28, 29, 30 113808 2VP75 1 5/8 110810 2BK70H 1-7/16 (2) BX83 - 92333 JM
Energy Efficient (Premium) Motor Drive Table
NOTES: 1” blower pulley applies to Cabinets A & B; 1-3/16” blower pulley applies to Cabinet C. Cabinet D has a 1-7/16” blower pulley.
Linked Belt - Assume 17 Fenner “A” or “B” belt links per foot. “A” Belt Link is P/N 201809. “B” Belt Link is P/N 202655.
If H x 1 “ bushing is required, order P/N 92203.
If H x 1 3/16” bushing is required, order P/N 106260
If H x 1 7/16” bushing is required, order P/N 89659.
Motor AK Option Drive AM Option CODE 75 - Motor Pulley CODE 76 - Blower Pulley
CODE 77 - Belt
(See Note for P/N’s.)
Serial No.
CODE (See
page 2.) HP Opt AL (Voltage) (See Key, page 12.) P/N Model Bore P/N Model Bore
1,
1-1/2,
2
36, 37, 38
AK5 (208/3);
AK6 (230/3);
AK7 (460/3);
AK8 (575/3)
1, 2 110125 1VP34 7/8
111609 AK 99 1 “A-section” 3.8 ft PJ
16154 AK 104 1-3/16 “A-section” 3.8 ft KK
3, 4 106748 1VL40 7/8
111609 AK 99 1 “A-section” 3.8 ft QJ
106255 AK 94 1-3/16 “A-section” 3.8 ft LK
5, 6, 7 106748 1VL40 7/8
19111 AK 84 1 “A-section” 3.8 ft RJ
111862 AK 84 1-3/16 “A-section” 3.8 ft MK
8, 9, 10, 11, 12 106748 1VL40 7/8
18797 AK 64 1 “A-section” 3.8 ft SJ
208608 AK 64 1-3/16 “A-section” 3.8 ft NK
13, 14, 15, 16, 17
106748 1VL40
7/8
135200 AK 51 1 “A-section” 3.8 ft OK
106758 1VL44 208610 AK 56 1-3/16 “A-section” 3.8 ft PK
18, 19, 20, 21, 22, 23,
24, 25
106758 1VL44 7/8
206125 AK44 1 “A-section” 3.8 ft XJ
194295 AK 44H 1-3/16 “A-section” 3.8 ft QK
26, 27, 28, 29
106758 1VL44
7/8
135201 AK39 1 “A-section” 3.8 ft YJ
106748 1VL40 194296 AK 32 H 1-3/16 “A-section” 3.8 ft RK
