Reznor MAPSIV RECC Parts Manuals - Manual (Page 19)

Form P-MAPS III&IV, PN 262958R5, Page 19
R-410A Cooling Components for MAPS ® III Cabinet “B” Sizes - Models RCB, RDB, RECB, REDB, RDCB, RDDB
Voltage - 3ph/60hz
RCB/RECB/RDCB 160 / RDB/REDB/RDDB 184
208-240 480 575
RCB/REB/RDCB 186 / RDB/REDB/RDDB 210 and 222
208-240 480 575 208-240 480 575
RCB/REB/RDCB 200 / RDB/REDB/RDDB 224 and 236
208-240 480 575 208-240 480 575
Code Description Crt Qty P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N
Compression
110 Compressors
A 1 216689 216690 216691 216686 216687 216688 216686 216687 216688
B 1 235008 235012 235016 235009 235013 235018 235009 235013 235018
C 1 235095 235097 235099 216686 216687 216688 235009 235013 235018
111 Molded Plug 3 205630 205630 205630
112
Thermostatic
Expansion
Valves
A 1 220555 220554 220554
B 1 220554 220555 220555
C 1 220552 220554 220555
113 Filter Driers
A 1 216408 177379 177379
B 1 177379 216408 216408
C 1 177378 177379 216408
114 Crankcase
Heaters
A 1 216398 216400 216401 216398 216400 216401 216398 216400 216401
B 1 216394 216396 216397 216398 216400 216401 216398 216400 216401
C 1 216394 216396 216397 216398 216400 216401 216398 216400 216401
Cooling Coils
120 Evaporator Coils
A&B 1 235106
235108 235109
C 1 235107
121 Condenser Coils
A 1 254984 254982 254982
B 1 254982 257322 257322
C 1 254980 254982 254983
Condenser Fan System
122 Fan Motors, 3/4 HP (2) 205628 (2) 205629 (2) 205628 (2) 205629 (2) 205628 (2) 205629
123 Fan Blades (2) 177223 (2) 177223 (2) 177223
124 Fan/Motor Support (2) 157107 (2) 157107 (2) 157107
125 Condenser Top
(1) 261869
(replaced 258436 2/11)
(1) 261869
(replaced 258436 2/11)
(1) 256166
126 Fan Guard (2) 177160 (2 ) 177160 (2) 177160
Reheat Circuit Components - Models RDB, REDB, RDDB only
110 Compressor DH DH 1
Model Size 184
235095 235097 235099
Model Size 210
235095 235097 235099
Model Size 222
235096 235098 235100
Model Size 224
235095 235097 235099
Model Size 236
235096 235098 235100
111 Molded Plug 1 205744 205744 205744 205744 205744
112 Thermostatic
Expansion Valve
DH 1 220552 220552 220553 220552 220553
113 Filter Drier DH 1 177378 177378 177379 177378 177379
114 Crankcase Heater DH 1 216434 216436 216437 216434 216436 216437 216394 216396 216397 216434 216436 216437 216394 216396 216397
120 Evaporator Coil DH 1 235110 235111 235111 235111 235111
121 Condenser Coil DH 1 235112 235113 235113 235113 235113
R-410A Cooling Components for MAPS ® III Cabinet “B” Sizes - Models RDCB, RDDB
Voltage - 3ph/60hz
RDCB 078 / RDDB 102
208-240 480 575
RDCB 090 / RDDB 1
14
208-240 480 575
RDCB 1
18 / RDDB 142
208-240 480 575
RDCB 136 / RDDB 162
208-240 480 575
Code Description Crt Qty P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N
Compression
110 Compressors
A 1 235008 235012 235016 235008 235012 235016 216689 216690 216691 235008 235012 235016
B 1 235095 235097 235099 235096 235098 235100 235096 235098 235100 235095 235097 235099
111 Molded Plug 2 205630 205630 205630 205630
112 Thermostatic Expansion Valves
A 1 220554 220554 220555 220554
B 1 220552 220553 220553 220552
113 Filter Driers
A 1 177379 177379 216408 177379
B 1 177378 177379 177379 177378
114 Crankcase Heaters
A 1 216394 216396 216397 216394 216396 216397 216398 216400 216401 216394 216396 216397
B 1 216434 216436 216437 216434 216436 216437 216394 216396 216397 216434 216436 216437
Cooling Coils
120 Evaporator Coil 1 259176 235104 235105 235104
121 Condenser Coils
A 1 254982 254982 254984 254984
B 1 256750 254981 254981 254982
Condenser Fan System
122 Fan Motors, 3/4 HP (1) 205628 (1) 205629 (1) 205628
(1)
205629
(2) 205628 (2) 205629 (2) 205628 (2) 205629
123 Fan Blades (1)177223 (1) 177223 (2) 177223 (2) 177223
124 Fan/Motor Support (1)157107 (1) 157107 (2) 157107 (2) 157107
125 Condenser Top (1) 261870 (replaced 258437 2/11)
(1) 261870 (replaced 258437
2/11 )
(1) 261869 (replaced 258436
2/11)
(1) 261869 (replaced 258436
2/11)
126 Fan Guard (1)177160 (1)177160 (2)177160 (2)177160
Reheat Circuit Components - Model RDDB only
110 Compressor DH DH 1
Model Size 102
235095 235097 235099
Model Size 1
14
235095 235097 235099
Model Size 142
235095 235097 235099
Model Size 162
235095 235097 235099
111 Molded Plug 1 205744 205744 205744 205744
112 Thermostatic Expansion Valve DH 1 220552 220552 220552 220552
113 Filter Drier DH 1 177378 177378 177378 177378
114 Crankcase Heater DH 1 216434 216436 216437 216434 216436 216437 216434 216436 216437 216434 216436 216437
120 Evaporator Coil DH 1 259177 235110 235110 235110
121 Condenser Coil DH 1 259178 235112 235112 235112
MAPS ® III Cabinet “A” Reheat Circuit Components - Models RDB, REDB, and RDDB only
110 Compressor DH DH 1
Size 084
235095 235097 235099
Size 102
235095 235097 235099
Size 1
14
235095 235097 235099
Size 142
235095 235097 235099
Size 162
235095 235097 235099
111 Molded Plug 1 205744 205744 205744 205744 205744
113 Thermostatic
Expansion Valve DH 1
220552 220552 220552 220552 220552
113 Filter Drier DH 1 177378 177378 177378 177378 177378
114 Crankcase Heater DH 1 216434 216436 216437 216434 216436 216437 216434 216436 216437 216434 216436 216437 216434 216436 216437
120 Evaporator Coil DH 1 259177 259177 235110 235110 235110
121 Condenser Coil DH 1 259178 259178 235112 235112 235112
