Form P-MAPS III&IV, PN 262958R5, Page 18
Cooling and Dehumidifying Components - Refrigerant is R-410A.
R-410A Cooling Components for MAPS ® III Cabinet “A” Sizes - Models RCB, RDB, RECB, REDB, RDCB, RDDB
Voltage - 3ph/60hz
RCB/RECB/RDCB
060 /
RDB/REDB/RDDB
084
208-240 480 575
RCB/RECB/RDCB
078 /
RDB/REDB/RDDB
102
208-240 480 575
RCB/RECB/RDCB
090 /
RDB/REDB/RDDB
11
4
208-240 480 575
RCB/RECB/RDCB
1
18 /
RDB/REDB/RDDB
142
208-240 480 575
RCB/RECB/RDCB
136 /
RDB/REDB/RDDB
162
208-240 480 575
Code Description Crt Qty P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N P/N
Compression
110 Compressors
A 1 235096 235098 235100 235008 235012 235016 235008 235012 235016 216689 216690 216691 235008 235012 235016
B 1 235095 235097 235099 235095 235097 235099 235096 235098 235100 235096 235098 235100 235095 235097 235099
111 Molded Plug 2 205630 205630 205630 205630 205630
112 Thermostatic
Expansion Valves
A 1 220553 220554 220554 220555 220554
B 1 220552 220552 220553 220553 220552
113 Filter Driers
A 1 177379 177379 177379 216408 177379
B 1 177378 177378 177379 177379 177378
114 Crankcase
Heaters
A 1 216394 216396 216397 216394 216396 216397 216394 216396 216397 216398 216400 216401 216394 216396 216397
B 1 216434 216436 216437 216434 216436 216437 216434 216436 216437 216394 216396 216397 216434 216436 216437
Cooling Coils
120 Evaporator Coil 1 259176 259176 235104 235105 235104
121 Condenser Coils
A 1 254981 254982 254982 254984 254984
B 1 256750 256750 254981 254981 254982
Condenser Fan System
122 Fan Motor, 3/4 HP (1)205628 (1)205629 (1)205628 (1)205629 (1)205628 (1)205629 (2)205628 (2)205629 (2)205628 (2)205629
123 Fan Blade (1)177223 (1)177223 (1)177223 (2)177223 (2)177223
124 Fan/Motor Support (1)157107 (1)157107 (1)157107 (2)157107 (2)157107
125 Condenser Top
(1) 261870 (replaced 258437
2/11)
(1) 261870 (replaced 258437
2/11)
(1) 261870 (replaced 258437
2/11)
(1) 261869 (replaced
258436 2/11)
(1) 261869 (replaced 258436
2/11)
126 Fan Guard (1)177160 (1)177160 (1)177160 (2)177160 (2)177160
Cooling and Dehumidifying (Reheat) Components for MAPS ® III & IV Cabinet Sizes A, B, and C
(4) Screw,
P/N 96450
126 - Fan
Guard
125 -
Condenser
Top
124 - Fan
Support
123 - Fan
Blades
122 - Fan
Motor
123 - Fan Blade
124 - Fan Support
126 - Fan Guard
122 - Fan Motor
125 -
Condenser
Top
(top of fan blade to top of panel)
1.26”
Torque fan blade
setscrew to
120 in lbs ±2.
110 - Compressor
- See P/N’s on
pages 18-23.
111 - Molded Plug and
Cable or Wiring Harness
for Compressor - 5’, P/N
205630; 12’, P/N 205744
115 - Compressor
Mounting Kit, P/N
205825
116 - Frostat,
P/N 177233
118 - Low
Refrigerant
Pressure
Switch for
R-410A,
P/N 216380
112 - Thermostatic
Expansion Valve - See
P/N’s on pages 18-23.
113 - Filter
Drier - See
P/N’s on
pages 18-23.
114 - Crankcase Heater
- See P/N’s on pages
18-23.
117 - High
Refrigerant
Pressure
Switch
(manual reset),
P/N 216379
125 - Condenser
Top
126 - Fan
Guard
123 - Fan Blades
124 - Fan Support
122 - Fan
Motor
364 - Vertical
Coil Support
(See page 38.)
Condenser Fans (1, 2, or 3)
Codes
115, 116,
117, & 118
- one per
compressor
Components - MAPS ® III Models
RCB, RDB, RECB, REDB, RDCB, RDDB, Cabinets A, B, & C
Screw, P/N 102033
Fender Washer,
P/N 194156
Condenser Top (D-Cab)
Corner Support (A, B or C Cab)
P/N 207760 - 4 Req’d
Motor
Support
Rubber Washer
(Isolator), P/N 268291
Fender Washer,
P/N 194156
Flat Washer,
P/N 1087
Nut,
P/N 217226
Fan Installation and
Fan Support
Cabinet C -
Vibration
Isolation
Hardware on
Fan Support
Compressor B
Compressor C
Compressor A
Compressor
Dh (Reheat)
