APPLICATION WINDOW
Overview
The Mbox Studio application window allows the server’s output to be viewed in either Window or Fullscreen mode on
the preview monitor.
Fullscreen - While in Fullscreen mode, the server’s output (i.e., video) will be displayed at "full screen" without any
user interface showing.
Window - While in Window mode, the application’s user interface will be displayed. The Window mode interface
contains three tabs: Mbox, Setup, and Pixel Map as shown in this sample screen below:
The function of the three Window mode tabs is as follows:
+
Mbox tab - used for previewing the server’s video output.
+
Setup tab - used to configure the server. Refer to
on page 32 for more details.
+
Pixel Map tab - used to configure the Pixel Map and its Art-Net output. Refer to
on page 77 for
more details.
Fullscreen Mode
Window Mode
Output to: Preview (Monitor) and Stage
Output to: Preview (Monitor) only
