174 MBOX ® STUDIO USER MANUAL
Keystone
Keystone
Mode
Keystone X
Moves the entire keystoned
image left and right
Keystone Y
Moves the entire keystoned
image up and down
Scale
Adjusts the size of the entire
keystoned image
Edge 1
Adjusts the position of the top
blend
Edge 2
Adjusts the position of the left
blend
Edge 3
Adjusts the position of the
bottom blend
Edge 4
Adjusts the position of the right
blend
Corner 1X
Bottom-left corner L/R
adjustment
Corner 1Y
Bottom-left corner U/D
adjustment
Corner 2X
Bottom-Right corner L/R
adjustment
Corner 2Y
Bottom-Right corner U/D
adjustment
Corner 3X Top-Left corner L/R adjustment
Corner 3Y
Top-Left corner U/D
adjustment
Corner 4X
Top-Right corner L/R
adjustment
Corner 4Y
Top-Right corner U/D
adjustment
Rotation
Rotation of entire keystoned
Shutter
Shape
Selects the shape of the
shutters from four modes
Red Red additive
Green Green additive
Blue Blue additive
Scale Adjusts the size of the shutters
Edge
Adjusts the soft edge of the
shutters
Shutter 1a
Bottom-left corner L/R
adjustment
Shutter 1b
Top-Left corner L/R
adjustment
Shutter 2a
Top-Left corner U/D
adjustment
Shutter 2b
Top-Right corner U/D
adjustment
Shutter 3a
Top-Right corner L/R
adjustment
Parameter Descriptions (Continued)
Fixture Parameter Description
Shutter
(continued)
Shutter 3b
Bottom-Right corner L/R
adjustment
Shutter 4a
Bottom-Right corner U/D
adjustment
Shutter 4b
Bottom-Left corner U/D
adjustment
Layer
Effect 1
2D or 3D effect applied to the
layer
Modifier 1a First modifier
Modifier 1b Second modifier
Effect 2
2D or 3D effect applied to the
layer
Modifier 2a First modifier
Modifier 2b Second modifier
Blend Mode
Adjusts how layer blends with
layers underneath
Draw Mode
Adjusts methods for drawing
the layer
Red Red subtractive
Green Green subtractive
Blue Blue subtractive
Opacity Transparency of the layer
Texture
Folder
Selects numbered content
folder from w/in Media folder
Texture File
Selects numbered file from
within Texture folder
Play Mode
Selects play mode of movie
content
Play Speed
Adjusts play speed of movie
content
In Frame Sets in-frame of movie content
Out Frame
Sets out-frame of movie
content
Sync Stream
Selects 1 of 16 channels for
playback synchronization
Sync Offset
Adjusts layer's playback sync
offset later/earlier
Frame
Blending
Adjusts the amount of
interframe blending for movie
content
Texture
X-Fade Type
Selects the type of crossfade
for 2D content on the layer
Texture
X-Fade Time
Adjusts the timing of 2D
crossfades on the layer
X Position Moves the layer left and right
Y Position Moves the layer up and down
Scale Adjusts the size of the layer
X Scale
Adjusts the width of content
on the layer
Parameter Descriptions (Continued)
Fixture Parameter Description
