178 MBOX ® STUDIO USER MANUAL
Play Mode
Values Play Mode
0 Forward Loop
1 Forward Loop, Pause when Layer Opacity = 0
2
Forward Loop, Pause and Reset to In-Point
when Layer Opacity = 0
10 Reverse Loop
11 Reverse Loop, Pause when Layer Opacity = 0
12
Reverse Loop, Pause and Reset to In-Point
when Layer Opacity = 0
20 Forward Once
21 Forward Once, Pause when Layer Opacity = 0
22
Forward Once, Pause and Reset to In-Point
when Layer Opacity = 0
30 Reverse Once
31 Reverse Once, Pause when Layer Opacity = 0
32
Reverse Once, Pause and Reset to In-Point
when Layer Opacity = 0
40-49 Forward Bounce
50-59 Reverse Bounce
60-69 Random
70-79 Forward Once - Restart on In Frame Change
80-89 Scrub - In Frame
90-99 Scrub - Out Frame
100-109 Forward Loop - Crossfade on Out Frame
110-119 Reverse Loop - Crossfade on In Frame
120-129 Forward Loop - Restart on In Frame Change
130-134 Timecode Sync (Strict Lock)
135 Timecode Sync then Freewheel
136 Timecode Jam Sync
140 - 149 Layer Slave
150 - 159 Layer Master - Forward Loop
160 - 169 Layer Master - Forward Once
180
Kiosk Mode Non-Looping, pause on last
frame of last file
181 Kiosk Mode Non-Looping -loop last file
182 Kiosk Mode Non-Looping - fade out last file
185 - 189 Kiosk Mode Looping
190 - 199 SMPTE Kiosk Mode
240 Playout Mode - last 5 seconds
241 Playout Mode - last 10 seconds
242 Playout Mode - last 15 seconds
243 Playout Mode - last 20 seconds
244 Playout Mode - last 30 seconds
250-255 Restart Movie from In Point
Frame Blending
Values Description
0 No Frame Blending (more accurately, blend time = 0)
1-255
Variable Frame Blend Time, as a proportion of the
frame time. This is a square-law control, and 50%
blend time is achieved at value 210, 25% blend time
at value 165.
Video Input and Utility (Texture Folder 255)
Texture
Value
Input
0 Patch Info Display
121 Layer Copy FX+ Layer 1
122 Layer Copy FX+ Layer 2
123 Layer Copy FX+ Layer 3
124 Layer Copy FX+ Layer 4
125 Layer Copy FX+ Layer 5
126 Layer Copy FX+ Layer 6
127 Layer Copy FX+ Layer 7
128 Layer Copy FX+ Layer 8
201 Syphon Input 1
202 Syphon Input 2
203 Syphon Input 3
204 Syphon Input 4
240 CG Color bars
254 Video Input 2
255 Video Input 1
TC DMX Control
The TC DMX controls are only required when the TC
DMX Control feature has been configured. (Refer to
"TC
DMX Controls" on page 66.) Each item in the TC DMX
Controls preference relates to one fixture that must be
patched to control timecode on a layer.
Chan Size Function Default Snap
1 1 Hours (0-23) 255 N
2 1 Minutes (0-59) 255 N
3 1 Seconds (0-59) 255 N
4 1 Frames (0-29) 255 N
