18 MBOX ® STUDIO USER MANUAL
Parameter Mapping
Summary: Single Output
Start Size Type Universe
1 4 Ambient Light
1st
410 Total
Channels
5 4 Spot Light 1
9 4 Spot Light 2
13 4 Spot Light 3
17 4 Spot Light 4
21 11 Master
32 20 Keystone
52 15 Shutter
67 43 Layer 1
110 43 Layer 2
153 43 Layer 3
196 43 Layer 4
239 43 Layer 5
282 43 Layer 6
325 43 Layer 7
368 43 Layer 8
Summary: Dual Output - Panoramic Wide
Start Size Type Universe
1 4 Ambient Light
1st
410 Total
Channels
5 4 Spot Light 1
9 4 Spot Light 2
13 4 Spot Light 3
17 4 Spot Light 4
21 11 Master
32 20 Keystone
52 15 Shutter
67 43 Layer 1
110 43 Layer 2
153 43 Layer 3
196 43 Layer 4
239 43 Layer 5
282 43 Layer 6
325 43 Layer 7
368 43 Layer 8
