PRG Mbox Studio Manual 3.8 User Manual
Page 181
MBOX
®
STUDIO USER MANUAL
173
Summary: Single Output
Start
Size
Type
Universe
1
4
Ambient Light
1st
410 Total
Channels
5
4
Spot Light 1
9
4
Spot Light 2
13
4
Spot Light 3
17
4
Spot Light 4
21
11
Master
32
20
Keystone
52
15
Shutter
67
43
Layer 1
110
43
Layer 2
153
43
Layer 3
196
43
Layer 4
239
43
Layer 5
282
43
Layer 6
325
43
Layer 7
368
43
Layer 8
Summary: Dual Output - Panoramic Wide
Start
Size
Type
Universe
1
4
Ambient Light
1st
410 Total
Channels
5
4
Spot Light 1
9
4
Spot Light 2
13
4
Spot Light 3
17
4
Spot Light 4
21
11
Master
32
20
Keystone
52
15
Shutter
67
43
Layer 1
110
43
Layer 2
153
43
Layer 3
196
43
Layer 4
239
43
Layer 5
282
43
Layer 6
325
43
Layer 7
368
43
Layer 8
Parameter Descriptions
Fixture
Parameter
Description
Ambient
Light
Intensity
The ambient light washes 3D
objects evenly from all sides,
no shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 1
Intensity
Spot 1 washes 3D objects
from top right, casting
shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 2
Intensity
Spot 2 washes 3D objects
from top left, casting shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 3
Intensity
Spot 3 washes 3D objects
from below, casting shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Spot Light 4
Intensity
Spot 4 washes 3D objects
from above, casting shadows
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Master
Pixel Map
Level
Intensity master for pixel-
mapping Art-Net output
Pixel Map
Control
Control functions for pixel-
mapping
Texture
Effect 1
2D effect applied to the final
Modifier 1a
First modifier
Modifier 1b
Second modifier
Red
Red subtractive
Green
Green subtractive
Blue
Blue subtractive
Intensity
Intensity of the video output
Control
Control functions for server -
HUDs, macros, etc.
Master Audio
Volume
Final output volume master
