Note: Keystone, Warp, and Blend settings created in the
Mbox Remote application will override any Art-Net
controlled keystone values.
Keystone
Chan
Size
Function
Default
Snap
1
1
0
Y
2
2
Keystone X
32767
N
4
2
Keystone Y
32767
N
6
2
Scale
65535
N
8
1
Edge 1 (top)
0
N
9
1
Edge 2 (left)
0
N
10
1
Edge 3 (bottom)
0
N
11
1
Edge 4 (right)
0
N
12
1
Corner 1-X
0
N
13
1
Corner 1-Y
0
N
14
1
Corner 2-X
0
N
15
1
Corner 2-Y
0
N
16
1
Corner 3-X
0
N
17
1
Corner 3-Y
0
N
18
1
Corner 4-X
0
N
19
1
Corner 4-Y
0
N
20
1
Keystone Rotation
127
N
Keystone Mode
Values
Mode
Curve
0
Use Remote Settings
n/a
1-8
Eighth Order
Steep
9
Eight Order w/ Grid
Steep
10-18
Fourth Order
Medium
19
Fourth Order w. Grid
Medium
20-28
Second Order
Shallow
29
Second Order w. Grid
Shallow
Shutter
Chan
Size
Function
Default
Snap
1
1
0
Y
2
1
Red
0
N
3
1
Green
0
N
4
1
Blue
0
N
6
2
Scale
32767
N
7
1
Edge
0
N
8
1
Shutter 1a
0
N
9
1
Shutter 1b
0
N
10
1
Shutter 2a
0
N
11
1
Shutter 2b
0
N
12
1
Shutter 3a
0
N
13
1
Shutter 3b
0
N
14
1
Shutter 4a
0
N
15
1
Shutter 4b
0
N
Shutter Shape
Values
Shape
Notes
0-9
Disabled
10-19
Moving
Light Mode
Separate controls for each end of
shutter. If both controls are zero,
shutter disappears.
20-29
Leko Mode
Distance and angle controls. If
distance is zero, shutter disappears.
30-39
Iris Mode
A round iris, scale is magnified to
enclose the screen. No other controls.
40-49
Blob Mode
A Bezier curve is drawn touching the
midpoints of the rectangle formed by
Leko Mode.
