TAP 100 Application Software Manual
Page 76 Revision 3.3
Status of Doors Table (continued)
Hexadecimal Digit Hexadecimal Value Binary Value Active Readers
xxxx xXxx if X is a . . . its value is . . . indicating the secured doors are . . .
0 0000 12, 11, 10, and 9
1 0001 12, 11, 10
2 0010 12, 11, and 9
3 0011 12 and 11
4 0100 12, 10, and 9
5 0101 12 and 10
6 0110 12 and 9
7 0111 12
8 1000 11, 10, and 9
9 1001 11 and 10
A 1010 11 and 9
B 1011 11
C 1100 10 and 9
D 1101 10
E 1110 9
F 1111 12, 11, 10, and 9 are not secured
xxxx Xxxx if X is a . . . its value is . . . indicating the secured doors are . . .
0 0000 16, 15, 14, and 13
1 0001 16, 15, and 14
2 0010 16, 15, and 13
3 0011 16 and 15
4 0100 16, 14, and 13
5 0101 16 and 14
6 0110 16 and 13
7 0111 16
8 1000 15, 14, and 13
9 1001 15 and 14
A 1010 15 and 13
B 1011 15
C 1100 14 and 13
D 1101 14
E 1110 13
F 1111 doors 16, 15, 14, and 13 are not secured
xxxX xxxx if X is a . . . its value is . . . indicating the secured doors are . . .
0 0000 20, 19, 18, and 17
1 0001 20, 19, and 18
2 0010 20, 19, and 17
3 0011 20 and 19
4 0100 20, 18, and 17
5 0101 20 and 18
6 0110 20 and 17
7 0111 20
8 1000 19, 18, and 17
9 1001 19 and 18
A 1010 19 and 17
B 1011 19
C 1100 18 and 17
D 1101 18
E 1110 17
F 1111 doors 20, 19, 18, and 17 are not secured
