Check Expansion Tank

Check Expansion Tank

Refer to Section IV - Boiler Piping for recom-
mended location of the expansion tank and
air eliminators.

Closed -Type Tank:

• Ensure tank is partially filled with water

leaving an air gap as a cushion. Refer
to the manufacturer’s instruction for
proper fill level.

• Ensure the tank is fitted with a device

that reduces gravity circulation of air-
saturated tank water back into the sys-
tem. This device prevents air from bub-
bling up through the water as it returns
from the system.

• Ensure no automatic air vents are

used in the system. This will allow air
to escape from the system instead of
returning to the tank.

Diaphragm Tank:

• Ensure the system contains a minimum

of one automatic air vent. Recommended
location of the air vent should be atop an
air eliminator.

• Remove the tank from the system and

check the charge pressure. For residen-
tial applications the charge pressure is
typically 12 psig. If tank does not hold
a charge pressure, then the membrane
is damaged and the tank should be
replaced.

Check Boiler Relief Valve

Inspect the relief valve and lift the lever to ver-
ify flow at least annually or as recommended
on the warning tag of the valve.

WARNING!

B

EFORE

MANUALLY

OPERATING

THE

PRESSURE

RELIEF

VALVE

,

ENSURE

THE

DISCHARGE

PIPING

IS

DIRECTED

TO

A

SUITABLE

PLACE

OF

DISPOS

-

AL

TO

AVOID

A

POTENTIAL

SCALD

HAZARD

. T

HE

DISCHARGE

PIPING

MUST

BE

FULL

SIZE

WITHOUT

RESTRICTION

AND

INSTALLED

TO

PERMIT

COM

-

PLETE

DRAINAGE

OF

BOTH

THE

VALVE

AND

LINE

.

If when closed, the valve fails to seat properly
or continually weeps and it has been deter-
mined that the cause is not system over-pres-
surization due to an undersized or waterlogged
expansion tank, replace the relief valve.

Inspect Ignition Electrode

1. Remove the ignition electrode from the

burner mounting plate.

2. Remove any white oxides on the electrode

using fine grit sandpaper or steel wool. If
the electrode does not clean to a satisfac-
tory condition, replace the ignitor .

3. Ensure the gasket is in good condition

and correctly positioned, replace gasket if
necessary.

GF-125
