3-2 Device Maps
3-12 - CC-Link Compatible Network Unit DL-CL1 User’s Manual (SK-1000) -
Comm
u
nic
a
ti
ng
w
it
h th
e
SK-1
000 Se
ri
es
3
The following device maps are used when the operating mode is monitor mode 2, full
mode 1, or full mode 2.
In cases of small-memory mode 1, small-memory mode 2, and monitor mode 1,
see "Device Maps for Small-Memory Mode 1, Small-Memory Mode 2, and Monitor
Mode 1" (page 3-4).
Remote input RX (DL-CL1 -> master station)
Device Maps for Monitor Mode 2, Full Mode 1, and Full Mode 2
Operating
mode
Device no.
(HEX)
Name
Communication
method
Description Reading range
M
oni
to
r m
ode
2
F
u
ll mo
de
1
F
u
ll mo
de
2
RX[n] + 00
to 07 HI ID 01
to ID 08
*1
Sends the HI output state (ON/
OFF) of the sensor amplifier.
The HI output of each sensor
amplifier (ID 01 to ID 08)
corresponds to each RX.
0: OFF
1: ON
RX[n] + 0F Error status -
The DL-CL1 is not communicating
properly with the sensor amplifier,
or an error exists with the sensor
amplifier.
If an error exists, the error code is
stored in error code (RWr[n] + 00).
0: No error
1: Error
RX[n] + 10
to 17 LO ID01
to ID08
*1
Sends the LO output state (ON/
OFF) of the sensor amplifier.
The LO output of each sensor
amplifier (ID 01 to ID 08)
corresponds to each RX.
0: OFF
1: ON
RX[n] + 1F Not used - - -
RX[n] + 20
to 27 GO ID01
to ID08
*1
Sends the GO output state (ON/
OFF) of the sensor amplifier.
The GO output of each sensor
amplifier (ID 01 to ID 08)
corresponds to each RX.
0: OFF
1: ON
RX[n] + 2F System reserved - Unusable -
RX[n] + 30
to 37 Alarm output
ID 01 to ID 08
*1 -
0: OFF
1: ON
RX[n] + 3F System reserved - Unusable -
RX[n] + 40
to 4E Not used
ID 01 to ID 08
- - -
RX[n] + 4F System reserved - Unusable -
RX[n] + 50 Sensor ready *3
Used when communicating under
handshake control program.
This is output when command
execution is ready.
0: In preparation
1: Ready
RX[n] + 51
Command
complete
*3
Used when communicating under
handshake control program.
This is output when command
execution is complete.
0->1: Execution
complete
RX[n] + 52 Command error *3
Used when communicating under
handshake control program.
This is output when an error occurs
during command execution.
0: No error
1: Error
RX[n] + 53
Judgment value
update lock
state
-
This is output when judgment
value update is locked (judgment
value update lock request (RY[n] +
53) is ON).
0: Update
enabled
1: Update locked
RX[n] + 54
to 5D System
reserved
- Unusable -
