3-2 Device Maps
3-11
3
Comm
u
nic
a
ti
ng
w
it
h th
e
SK-1
000 Se
ri
es
- CC-Link Compatible Network Unit DL-CL1 User’s Manual (SK-1000) -
Number [n] denotes the first relay number assigned to the DL-CL1.
*1
Refer to
*2
Refer to
"Changing the BANK Number of Sensor Amplifiers" (page 3-21).
*3
Refer to
"Reading/Writing Settings or Status of a Sensor Amplifier" (page 3-23).
Refer to
"Issuing a Motion Command to a Sensor Amplifier" (page 3-22).
*4
Refer to
"Command Parameter List" (page 3-26).
Mo
ni
to
r mo
de
1
RWw[n] + 04
Select BANK
number
*2
Used when changing BANK
number.
Specifies a new BANK number.
0: BANK 0
1: BANK 1
2: BANK 3
3: BANK 3
RWw[n] + 05
to 07
System reserved
-
Unusable
-
RWw[n] + 08
Select
judgment value
box page
number
*1
Used when reading judgment
value (P.V. value).
Specifies the page number
corresponding to the sensor
amplifier ID number to be stored in
the
judgment value box.
0: Page 0
1: Page 1
2: Page 2
3: Page 3
4: Page 4
Operating
mode
Device no.
(HEX)
Name
Communication
method
Description
Writing range
