3-2 Device Maps
3-8 - CC-Link Compatible Network Unit DL-CL1 User’s Manual (SK-1000) -
Comm
u
nic
a
ti
ng
w
it
h th
e
SK-1
000 Se
ri
es
3
Number [n] denotes the first relay number assigned to the DL-CL1.
*1 Refer to "Entering an External Input into a Sensor Amplifier" (page 3-18).
*2 Refer to "Monitor mode 1" (page 3-19).
*3 Refer to "Reading/Writing Settings or Status of a Sensor Amplifier" (page 3-23).
Refer to "Issuing a Motion Command to a Sensor Amplifier" (page 3-22).
*4 Refer to "Monitor mode 2/full mode" (page 3-20).
*5 Refer to "Error information list" (page 3-9).
*6 Refer to "Command response list" (page 3-10).
*7 Refer to "Command Parameter List" (page 3-26).
Mo
ni
to
r mo
de
1
RWr[n] + 07
Judgment value
property
*2
Used when reading judgment
value (P.V. value).
This property is output by
assigning IDs (ID 01 to ID 08) to
bits 0 - 07.
The output occurs when the
judgment value (P.V. value) read
from the sensor amplifier is
nonnumeric: "over," "under," or
"invalid."
0: Normal
judgment value
1: "over," "under,"
or "invalid (-----)"
RWr[n] + 08
to 09 Judgment value
box 1
*2
Used when reading judgment
value (P.V. value).
The judgment value (P.V. value) of
the sensor amplifier of the ID
number specified page number
(RWw[n] + 08) is output.
Data type: INT32 (LITTLE)
Page 0: ID 01
Page 1: ID 04
Page 2: ID 07
RWr[n] + 0A
to 0B Judgment value
box 2
*2
Used when reading judgment
value (P.V. value).
The judgment value (P.V. value) of
the sensor amplifier of the ID
number specified page number
(RWw[n] + 08) is output.
Data type: INT32 (LITTLE)
Page 0: ID 02
Page 1: ID 05
Page 2: ID 08
RWr[n] + 0C
to 0D Judgment value
box 3
*2
Used when reading judgment
value (P.V. value).
The judgment value (P.V. value) of
the sensor amplifier of the ID
number specified page number
(RWw[n] +08) is output.
Data type: INT32 (LITTLE)
Page 0: ID 03
Page 1: ID 06
Page 2: Not used
RWr[n] + 0E
External input-4
response
*1
Stores the external input-4
response of the sensor amplifier.
The response is output by
assigning sensor amplifiers (ID 01
to ID 08) to bits 0 - 07.
0: Input OFF
1: Input ON
RWr[n] + 0F (Not used) - - -
Operating
mode
Device no.
(HEX)
Name
Communication
method
Description Reading range
