2-1 Installation and Connection to Sensor Amplifiers
2-3
2
Connec
ti
on and
Conf
ig
u
ration
- CC-Link Compatible Network Unit DL-CL1 User’s Manual (SK-1000) -
Mounting on a DIN rail
1
Align the claw on the bottom of the amplifier with the DIN rail. While push-
ing the amplifier in the direction of arrow (1), press down in the direction
of arrow (2).
2
To remove the DL-CL1, raise the main unit in the direction of arrow (3)
while pushing it the direction of arrow (1).
Installation and Connection to Sensor Amplifiers
(1)
(2)
(3)
