3-4
3
Comm
u
nic
a
ti
ng
w
it
h th
e
SK-1
000 Se
ri
es
- CC-Link Compatible Network Unit DL-CL1 User’s Manual (SK-1000) -
3-2
Device Maps
The device maps vary as described in "Selecting an Operating Mode of the DL-
CL1" (page 3-3). Select an operating mode suited for the functions of the sensor
amplifiers to be used, before accessing each device.
The following device maps are used for when the operating mode is small-memory
mode 1, small-memory mode 2, or monitor mode 1.
In cases of monitor mode 2, full mode 1, and full mode 2, see "Device Maps for
Monitor Mode 2, Full Mode 1, and Full Mode 2" (page 3-12).
Remote input RX (DL-CL1 -> master station)
Device Maps for Small-Memory Mode 1, Small-Memory Mode 2, and Monitor Mode 1
Operating
mode
Device no.
(HEX)
Name
Communication
method
Description Reading range
S
m
a
ll-m
e
mo
ry mo
de
1
S
m
a
ll-m
e
mo
ry mo
de
2
M
oni
to
r m
ode
1
RX[n] + 00
to 07 HI ID 01
to ID 08
*1
Sends the HI output state (ON/
OFF) of the sensor amplifier.
The HI output of each sensor
amplifier (ID 01 to ID 08)
corresponds to each RX.
0: OFF
1: ON
RX[n] + 0F Error status -
The DL-CL1 is not communicating
properly with the sensor amplifier,
or an error exists with the sensor
amplifier.
If an error exists, the error code is
stored in error code (RWr[n] + 00).
0: No error
1: Error
RX[n] + 10
to 17 LO ID 01
to ID 08
*1
Sends the LO output state (ON/
OFF) of the sensor amplifier.
The LO output of each sensor
amplifier (ID 01 to ID 08)
corresponds to each RX.
0: OFF
1: ON
RX[n] + 1F (Not used) - - -
RX[n] + 20
to 27 GO ID01
to ID08
*1
Sends the GO output state (ON/
OFF) of the sensor amplifier.
The GO output of each sensor
amplifier (ID 01 to ID 08)
corresponds to each RX.
0: OFF
1: ON
RX[n] + 2F System reserved - Unusable -
RX[n] + 30
to 37 Alarm output
ID 01 to ID 08
*1 -
0: OFF
1: ON
RX[n] + 3F System reserved - Unusable -
RX[n] + 40
to 4E (Not used)
ID 01 to ID 08
- - -
RX[n] + 4F System reserved - Unusable -
RX[n] + 50 Sensor ready *4
Used when communicating under
handshake control program.
This is output when command
execution is ready.
0: In preparation
1: Ready
RX[n] + 51
Command
complete
*4
Used when communicating under
handshake control program.
This is output when command
execution is complete.
0->1: Execution
complete
