3-2 Device Maps
3-9
3
Comm
u
nic
a
ti
ng
w
it
h th
e
SK-1
000 Se
ri
es
- CC-Link Compatible Network Unit DL-CL1 User’s Manual (SK-1000) -
Error information list
* "nn" denotes the ID number in hexadecimal of sensor amplifier.
(Example: 01h for ID 01, ..., 04h for ID 04)
If there are multiple errors, the smallest error code is stored in the remote register.
Error Information
(HEX) *
Description Cause Corrective action
0000 No error - -
0001
0002
0005
Initialization error
Error encountered during
initialization.
Check the number of connected
sensor amplifiers and the
connection to the sensor
amplifiers, and then turn off the
power and back on. If the error
cannot be recovered, contact
your nearest sales office.
0003 Model error
There is connected a sensor
amplifier of a model
incompatible with the DL-CL1.
Connect a sensor amplifier of a
compatible model.
0004 Mixed connection error
A foreign sensor amplifier (i.e.,
one that cannot be intermixed)
is connected.
Remove the foreign sensor
amplifier.
0006 Number-of-units error
More sensor amplifiers are
connected than are permitted. Observe the number of
connectable sensor amplifiers.
0007
Sensor-to-sensor
communication error
An error exists in the
communication between
sensor
amplifiers.
Check the connections of the
sensor amplifiers, and then turn
off the power and back on.
nn01
Error 1 for sensor amplifier
of ID number nn
Overcurrent error
Refer to the SK-1000 series
instruction manual.
nn02
Error 2 for sensor amplifier
of ID number nn
EEPROM error
nn03
Error 3 for sensor amplifier
of ID number nn
Head error
nn04 to nn07
Error 4 to 7 for sensor
amplifier of ID number nn
(Not used)
nn08
Error 8 for sensor amplifier
of ID number nn Head temperature/humidity
error
nn09 to nn0B
Error 9 to 11 for sensor
amplifier of ID number nn
(Not used)
nn0c
Error 12 for sensor amplifier
of ID number nn Amp-to-Amp communication
error
nn0D to nn10
Error 13 to 16 for sensor
amplifier of ID number nn
(Not used)
